Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, Shimano -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Sora 9-Speed
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora 2x9-Speed
Cassette
SunRace 9-Speed, 11-32T
Crank
Shimano R345 Octalink Compact, 50/34T
Bottom Bracket
Shimano Octalink V2 Cartridge
Chain
KMC X9
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, 19mm Inner, 24mm Tall, Disc Specific, Tubeless Compatible
Tires
WTB, Exposure Comp, 700Cx32mm, Wire Bead
Brakes
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Perforated Tape
Headset
FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.49 mm | 1.53 mm | 1.52 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 589 mm | 590 mm | 595 mm | 615 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 61 mm | 61 mm | 61 mm | 61 mm | 58 mm |
| Stack | 544.5 mm | 562.4 mm | 576.7 mm | 595.7 mm | 614.7 mm | 635.8 mm |
| Reach | 371.6 mm | 376.3 mm | 376.8 mm | 391.1 mm | 399.7 mm | 408.2 mm |
| Top Tube Length | 522 mm | 537 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 995 mm | 996 mm | 1001 mm | 1021 mm | 1036 mm | 1046 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 715 mm | 734 mm | 753 mm | 776 mm | 795 mm | 815 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Gestalt 1 belongs to the Marin Gestalt model. Marin launched 42 bikes of this model so far. Take a sneak peek at all Marin Gestalt bikes models from 2021, by clicking here.
Model range prices
Marin Gestalt 2021 is the most affordable bike of this model and has a price of 979$. On the other hand, Marin Gestalt X11 2021, is the most expensive and costs 2369$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Marin released this model in 2021, its price was 1259$. Comparing the average cost of a Gravel bike to this one, you will see that Gestalt 1 price is 95.55% smaller.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Gestalt 1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Marin Gestalt 1 2021, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Gestalt 1 is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
