Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Beyond Road, 6061 Aluminum, 700C Wheels, Relieved Head Tube and BB, Internal Cable Routing, Post Mount Disc Specific Forged Dropouts
Suspension Fork
6061 Aluminum, Straight-Blade, Post-Mount Disc
Drivetrain
Rear Derailleur
Shimano Claris 8-Speed
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 2x8-Speed
Cassette
SunRace 8-Speed, 11-34T
Crank
FSA Tempo Compact, 50/34T
Bottom Bracket
Sealed Bearing Square Taper
Chain
KMC X8
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 19mm Inner, 25mm Tall, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
WTB, Exposure Comp, 700Cx32, Wire Bead
Brakes
Brakes
Promax Render R Road Mechanical Disc
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Perforated Tape
Headset
FSA No.8B
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.05 mm | 1.53 mm | 1.52 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 589 mm | 590 mm | 595 mm | 615 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 222 mm | 61 mm | 61 mm | 61 mm | 58 mm |
| Stack | 544.5 mm | 562.4 mm | 576.7 mm | 595.7 mm | 614.7 mm | 635.8 mm |
| Reach | 371.6 mm | 537 mm | 376.8 mm | 391.1 mm | 399.7 mm | 408.2 mm |
| Top Tube Length | 522 mm | 537 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 995 mm | 996 mm | 1001 mm | 1021 mm | 1036 mm | 1046 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 715 mm | 734 mm | 753 mm | 776 mm | 795 mm | 815 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Gestalt completes the Marin Gestalt model. 42 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
The most economical model, the Marin Gestalt 2019 has a starting price of 829$. Marin Gestalt X11 2019 on the other hand is the most expensive at 2199$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2019 and its price was 829$. Comparing the average cost of a Gravel bike to this one, you will see that Gestalt price is 196.98% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Gestalt components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The Gestalt 2019 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
