Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Rival 1, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
Marin Full Carbon w/ Taper Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
SRAM Rival 1 11-Speed
Front Derailleur
-
Shift Levers
SRAM Rival 1x11 Speed, Left Side Modified For Dropper Post Lever
Cassette
SRAM XG-1150 11-Speed, 10-42T
Crank
FSA Gossamer Pro, Megatooth 42T Chainring, BB386EVO Alloy Spindle
Bottom Bracket
FSA MegaExo Threaded
Chain
KMC X11
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 100x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, Alloy Axle, Quad Cartridge Sealed Bearings, SRAM XD Driver, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, 30mm Tall, Disc Specific, Tubeless Compatible
Spokes
Double Butted Stainless
Tires
WTB, Riddler TCS Light, 700Cx37, Folding Bead, Tubeless Compatible
Brakes
Brakes
SRAM Rival Hydraulic Disc, 160mm Rotor
Brake Levers
SRAM Rival Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop, Flat Top
Grips
Marin Shock Absorbing Perforated Tape
Headset
FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin Beyond Road Concept Elite
Seatpost
TranzX YSP11 Dropper Post, 105mm Travel, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.51 mm | 1.55 mm | 1.55 mm | 1.56 mm | 1.58 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 597 mm | 598 mm | 604 mm | 619 mm | 634 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 67 mm | 67 mm | 64 mm | 64 mm | 61 mm |
| Stack | 547.6 mm | 563.7 mm | 577.8 mm | 598.7 mm | 617.7 mm | 638.7 mm |
| Reach | 372 mm | 372.1 mm | 372.5 mm | 386.3 mm | 394.8 mm | 403.4 mm |
| Top Tube Length | 519 mm | 534 mm | 544 mm | 564 mm | 584 mm | 599 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 998 mm | 999 mm | 1004 mm | 1020 mm | 1035 mm | 1045 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 665 mm | 582 mm | 693 mm | 713 mm | 726 mm | 746 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Gestalt X11 is part of the Marin Gestalt model. There are 42 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Marin Gestalt 2019 is the cheapest bike model and costs 829$. Marin Gestalt X11 2019 is the most expensive one and costs 2199$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 2199$. In conclusion, this bike price is 11.96% lower than the price of the average Gravel bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Gestalt X11 components
Fork material
Gestalt X11 has a carbon fork, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Marin Gestalt X11 2019, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Gestalt X11 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Marin Gestalt X11 includes a dropper post. Therefore, climbing or descending will be a breeze.
