Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
154cm - 164cm
SM
161cm - 172cm
MD
169cm - 179cm
LG
176cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 27.5” Wheels, 120mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs
Suspension Fork
RockShox Recon RL 27.5", 130mm Travel, Solo Air, Compression and Rebound Adjustment, Alloy Tapered Steerer, Fast Black Uppers, 110x15mm Boost Spacing, Maxle Stealth, 46mm Offset
Rear Shock
X-Fusion O2 Pro R, 210x50mm, Custom Tune, 25mm x M8 Hardware Top and Bottom
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus Direct Mount 10-Speed
Front Derailleur
-
Shift Levers
Shimano Deore 1x10-Speed
Cassette
SunRace 10-Speed, 11-46T
Crank
Marin Forged Alloy 1x10, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X10
Chain Guide
None
Pedals
-
Wheels
Front Hub
Forged Alloy, 110x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Alloy, 148x12mm, Quad Sealed Bearings, 6-Bolt Disc, 32H, Standard Feehub Body
Rims
Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire, Crown Gem 27.5x2.3", Dual Control Compound, Folding Bead, Tubeless Compatible
Brakes
Brakes
Shimano BR-MT201 Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano BR-MT201 Hydraulic Disc
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm rise, 5º Up, 9º Back
Grips
Marin MTN, Closed End
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.32 mm | 1.29 mm | 1.24 mm |
| Bottom Bracket Height | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm |
| Front Center | 700 | 717 mm | 739 mm | 763 mm | 785 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 109 mm | 109 mm | 109 mm | 109 mm | 109 mm |
| Stack | 577 mm | 581.6 mm | 586.2 mm | 595.3 mm | 599.9 mm |
| Reach | 408 mm | 423 mm | 443 mm | 463 mm | 483 mm |
| Top Tube Length | 568.6 mm | 584.8 mm | 606.1 mm | 630.9 mm | 649.9 mm |
| Seat Tube Angle | 75 ° | 74.7 ° | 74.5 ° | 74.3 ° | 74.1 ° |
| Seat Tube Length | 330 mm | 380 mm | 425 mm | 470 mm | 515 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1127 mm | 1144 mm | 1166 mm | 1190 mm | 1212 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 645 mm | 663 mm | 700 | 725 mm | 766 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 161 cm | 169 cm | 176 cm | 184 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm | 187 cm | 193 cm |
Model Overview
Hawk Hill 1 belongs to the Marin Hawk model. There are 13 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
The most economical model, the Marin Hawk Hill JR 2019 has a starting price of 1599$. Marin Hawk Hill 3 2019 on the other hand is the most expensive at 2649$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Marin Hawk Hill 1 price was 1599$. Comparing the average cost of a Trail bike to this one, you will see that Hawk Hill 1 price is 72.73% smaller.
Hawk Hill 1 components
Fork
Marin Hawk Hill 1 2019 bike is equipped with the RockShox Recon Silver RL fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The Hawk Hill 1 has a rear shock with a travel of 120mm. The model X-Fusion O2 Pro R is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Hawk Hill 1 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Hawk Hill 1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 154 cm – 193 cm (5.05 ft – 6.33 ft). In conclusion, you won’t have a problem finding one that suits you.
