Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 120mm -
Travel Rear 120mm -
Fork X Fusion
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 24" wheel with clearance for up to 26", 120mm Travel, MultiTrac Suspension Platform, 135mm Open Dropout (Upgradeable to 142x12mm Thru-Axle), 73mm Threaded BB
Suspension Fork
X-Fusion Velvet RLC 26", 120mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus
Front Derailleur
-
Shift Levers
Micro Shift, SLM895, 11 speed
Cassette
SunRace 11-Speed, 11-46T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow-Wide 32T Chainring, Direct Mount Type
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Forged Alloy, 100x15mm, Centerlock Disc, 32H
Rear Hub
Forged Alloy, 135mm, Quad Sealed Bearings, Centerlock Disc, 32H
Rims
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Stainless Steel
Tires
Vee Tire Co, Flow Snap 24x2.4", Tackee Compound, Wire Bead
Brakes
Brakes
Shimano MT-201 Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano BL-MT201 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 720mm Width, 4º Up, 9º Back
Grips
Marin Dual Density
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 13" |
|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.411 mm |
| Bottom Bracket Height | 305 mm | 305 mm |
| Front Center | 590 mm | 590 mm |
| Rake | 42 mm | 42 mm |
| Stack | 539.24 mm | 536.24 mm |
| Reach | 383 mm | 380 mm |
| Top Tube Length | 539 mm | 536 mm |
| Seat Tube Angle | 69 ° | 73.5 ° |
| Seat Tube Length | 335 mm | mm |
| Head Tube Angle | 67.5 ° | 67.5 ° |
| Head Tube Length | 105 mm | 105 mm |
| Chainstay Length | 431 mm | 428 mm |
| Wheelbase | 1021 mm | 1018 mm |
| Bottom Bracket Drop | 10 mm | 10 mm |
| Standover Height | 624 mm | 621 mm |
| Wheels | 24" | 24" |
Model Overview
Hawk Hill Jr. completes the Marin Hawk model. Marin released 13 bikes variations of this model so far. Take a sneak peek at all Marin Hawk bikes models from 2018, by clicking here.
Model range prices
Marin Hawk Hill 2018 is the most affordable bike of this model and has a price of 1499$. On the other hand, Marin Hawk Hill 3 2018, is the most expensive and costs 2649$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Youth bikes
If you want to purchase a solid Youth bike, it is important to know that the average cost is 278$. However, this doesn’t mean that if you spend less money on a Youth bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1599$. Doing a quick comparison, we notice that Hawk Hill Jr. price is 475.18% higher than the average cost of a Youth bike.
Hawk Hill Jr. components
Fork
This bike has the X Fusion fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The Hawk Hill Jr. 2018 bike is equipped with 24″ aluminum wheels when leaving the factory. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
