Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 20” Wheels, IS Seatstay Disc Mounts, 135mm Dropouts
Suspension Fork
Steel Rigid Fork, 100mm Spacing, QR Lever
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
-
Shift Levers
Shimano Revo Twist 1x7-Speed
Cassette
Shimano HG20, 12-28T
Crank
Forged Alloy, 36T, 140mm, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Formula, 32H
Rear Hub
Formula, 32H
Rims
Marin, Double Wall Alloy
Spokes
14g Stainless Steel
Tires
Multi Surface, 20” x 2.125”
Brakes
Brakes
Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
Brake Levers
Kids Specific Short Reach Alloy Lever
Cockpit
Stem
Marin Alloy, 60mm
Handlebar
Marin Riser, 30mm Rise, 590mm Width
Grips
Marin Dual Density
Headset
FSA, Threaded
Seat
Saddle
Marin Kids MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.49 mm |
| Bottom Bracket Height | 232 mm |
| Front Center | 484 mm |
| Rake | 33 mm |
| Stack | 432.39 mm |
| Reach | 290.66 mm |
| Top Tube Length | 425 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 308 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 373 mm |
| Wheelbase | 855 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 504 mm |
| Wheels | 20" |
Model Overview
Hidden Canyon 20″ is a Marin Hidden model. Marin released 13 bikes variations of this model so far. Take a sneak peek at all Marin Hidden bikes models from 2020, by clicking here.
Model range prices
Marin Hidden Canyon 20″ 2020 is the cheapest bike model and costs 389$. Marin Hidden Canyon 2020 is the most expensive one and costs 399$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Youth bikes
According to our math, the average price for a trustworthy Youth bike is 278$. However, this doesn’t mean that if you spend less money on a Youth bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2020 and its price was 389$. Doing a quick comparison, we notice that Hidden Canyon 20″ price is 39.93% more expensive than the average cost of a Youth bike.
Overview of components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
As for the wheels, Marin Hidden Canyon 20″ 2020, has a 20″ aluminum model. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Hidden Canyon 20″ has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
