Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 20” Wheels, IS Seatstay Disc Mounts, 135mm Dropouts
Suspension Fork
Steel Rigid Fork, 100mm Spacing, QR Lever
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
-
Shift Levers
Shimano Revo Twist 1x7-Speed
Cassette
Shimano HG20, 12-28T
Crank
Forged Alloy, 36T, 140mm, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Wheels
Front Hub
Formula, 32H
Rear Hub
Formula, 32H
Rims
Marin, Double Wall Alloy
Spokes
14g Stainless Steel
Tires
Multi Surface, 20”x2.125”
Brakes
Brakes
Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
Brake Levers
Kids Specific Short Reach Alloy Lever
Cockpit
Stem
Marin Alloy, 60mm
Handlebar
Marin Riser, 30mm Rise, 590mm Width
Grips
Marin Dual Density
Headset
FSA, Threaded
Seat
Saddle
Marin Kids MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.49 mm |
| Bottom Bracket Height | 232 mm |
| Front Center | 484 mm |
| Rake | 33 mm |
| Stack | 432.39 mm |
| Reach | 290.66 mm |
| Top Tube Length | 425 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 308 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 373 mm |
| Wheelbase | 855 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 504 mm |
| Wheels | 20" |
About this model
Hidden Canyon completes the Marin Hidden model. 13 bikes variations carry this model name so far. You can easily view all of the Marin Hidden bikes models from 2020, here.
Model range prices
Marin Hidden Canyon 20″ 2020 is the cheapest bike model and costs 389$. Marin Hidden Canyon 2020 is the most expensive one and costs 399$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Youth bikes average price
If you want to purchase a solid Youth bike, it is important to know that the average cost is 278$. However, you could also get a good Youth bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2020 and its price was 399$. If we compare this with the average Youth bike cost we notice that the price is 43.53% higher.
Hidden Canyon components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When leaving the production line, the Hidden Canyon model has 20″ aluminum wheels. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Hidden Canyon is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
