Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset microSHIFT Advent X -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
149cm - 159cm
SM
156cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Butted CrMo, 29” Wheels, Integrated Headset, Disc Brake, Fender and Rack Mounts
Suspension Fork
Steel, Moto Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
MicroSHIFT Advent X 10-Speed
Front Derailleur
-
Shift Levers
MicroSHIFT Advent X 10-Speed Trail
Cassette
SunRace 10-Speed, 11-51T
Crank
Forged Alloy Crank, Steel Narrow Wide 38T Chainring
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X10
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum, Double Wall, Disc Specific
Tires
WTB Riddler, 700Cx45mm
Brakes
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Marin Alloy, 31.8mm Clamp
Handlebar
Marin Alloy Mini Riser
Grips
Marin Custom
Headset
FSA No.8B, Sealed Cartridge Bearings
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.41 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 289.5 mm | 289.5 mm | 289.5 mm | 289.5 mm | 289.5 mm |
| Front Center | 636 mm | 669 mm | 701 mm | 734 mm | 766 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 558.7 mm | 577.2 mm | 595.6 mm | 614.1 mm | 632.6 mm |
| Reach | 372 mm | 397 mm | 422 mm | 447 mm | 472 mm |
| Top Tube Length | 533 mm | 563.4 mm | 593.7 mm | 624 mm | 654.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm | 530 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1052 mm | 1084 mm | 1117 mm | 1150 mm | 1182 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 630 mm | 669 mm | 700 | 728 mm | 748 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 156 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 159 cm | 169 cm | 179 cm | 189 cm | 193 cm |
Model Overview
Muirwoods belongs to the Marin Muirwoods model. There are 13 bikes that carry this model name. Take a sneak peek at all Marin Muirwoods bikes models from 2022, by clicking here.
Model range prices
Marin Muirwoods 2022 is the most affordable bike of this model and has a price of 999$. On the other hand, Marin Muirwoods RC 2022, is the most expensive and costs 1159$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter bikes
If you want an acceptable Commuter bike you should know that the average price is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2022 for 999$. Comparing this to the average Commuter bike price, we see that the price is 31.1% more expensive.
Muirwoods components
Fork material
Muirwoods has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When leaving the production line, the Muirwoods model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Muirwoods comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 5 sizes. They vary from 149 cm – 193 cm (4.89 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
