Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Double Butted CrMo w/Marin Slider Dropouts, 650B Wheels, Flat Mount Disc Brake, Fender and Rack Mounts, Rear Kickstand Mount
Suspension Fork
CrMo, Fender and Rack Eyelets, IS Disc Mount
Drivetrain
Shift Levers
MicroSHIFT 8-Speed Thumb Shifter
Cassette
Shimano Nexus Cog, 19T
Crank
Forged Aluminum, Alloy Ring Guard, 42T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z410RB w/ Anti-Corrosion Coating
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, Centerlock Disc, 32H
Rear Hub
Shimano Nexus 8-Speed Internally Geared Hub, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 27mm Inner, Disc Specific
Tires
WTB Horizon, 650Bx47mm, Wire Bead
Brakes
Brake Levers
Shimano BL-M201 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Alloy Swept-Back City Bar, 31.8mm Clamp
Grips
Marin Locking
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.35 mm | 1.32 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 605 mm | 612 mm | 643 mm | 675 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 70 mm | 64 mm | 64 mm | 63 mm |
| Stack | 536.37 mm | 554.22 mm | 572.11 mm | 592.15 mm |
| Reach | 388 mm | 398 mm | 423 mm | 448 mm |
| Top Tube Length | 537.3 mm | 562.76 mm | 593.24 mm | 624 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 521 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1012 mm | 1018 mm | 1050 mm | 1081 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 637 mm | 685 mm | 729 mm | 762 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 193 cm |
Model Overview
Muirwoods RC is a Marin Muirwoods model. There are 13 bikes that carry this model name. You can easily view all of the Marin Muirwoods bikes models from 2022, here.
Model range prices
The most economical model, the Marin Muirwoods 2022 has a starting price of 999$. Marin Muirwoods RC 2022 on the other hand is the most expensive at 1159$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2022 for 1159$. Comparing this to the average Commuter bike price, we see that the price is 52.1% higher.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
As for the wheels, Marin Muirwoods RC 2022, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Muirwoods RC comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Muirwoods RC comes in 4 sizes, that range from 157 cm – 193 cm (5.15 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
