Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Double Butted CrMo w/Marin Slider Dropouts, 650B Wheels, Flat Mount Disc Brake, Fender and Rack Mounts, Rear Kickstand Mount
Suspension Fork
CrMo, Fender and Rack Eyelets, IS Disc Mount
Drivetrain
Shift Levers
MicroSHIFT 8-Speed Thumb Shifter
Cassette
Shimano Nexus Cog, 19T
Crank
Forged Aluminum, Alloy Ring Guard, 42T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z410RB w/ Anti-Corrosion Coating
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, Centerlock Disc, 32H
Rear Hub
Shimano Nexus 8-Speed Internally Geared Hub, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 27mm Inner, Disc Specific
Spokes
14g Black Stainless Steel
Tires
WTB Horizon, 650Bx47, Wire Bead
Brakes
Brakes
Shimano BR-M201 Hydraulic Disc, 160mm Rotor
Brake Levers
Shimano BL-M201 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Alloy Swept-Back City Bar, 31.8mm Clamp
Grips
Marin Locking
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.39 mm | 1.35 mm | 1.32 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 605 mm | 612 mm | 643 mm | 675 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 70 mm | 64 mm | 64 mm | 63 mm |
| Stack | 536.37 mm | 554.22 mm | 572.11 mm | 592.15 mm |
| Reach | 388 mm | 398 mm | 423 mm | 448 mm |
| Top Tube Length | 537.3 mm | 562.76 mm | 593.24 mm | 624 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 521 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1012 mm | 1018 mm | 1050 mm | 1081 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 637 mm | 685 mm | 729 mm | 762 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 160 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 169 cm | 177 cm | 184 cm | 188 cm |
About this model
Muirwoods RC is part of the Marin Muirwoods model. Marin released 13 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Marin Muirwoods 2020 is the cheapest bike model and costs 749$. Marin Muirwoods RC 2020 is the most expensive one and costs 999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter bikes average price
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Marin Muirwoods RC price was 999$. Doing a quick comparison, we notice that Muirwoods RC price is 31.1% higher than the average cost of a Commuter bike.
Overview of components
Fork material
Muirwoods RC has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When leaving the production line, the Muirwoods RC model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Muirwoods RC has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Marin Muirwoods RC bike has 4 sizes, in the range of 160 cm – 188 cm (5.25 ft – 6.17 ft). In short, it won’t be difficult to find the right one for you.
