Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 CrMo, Beyond Road Geometry, Thru- Axle, Disc Brake, Integrated Headset, Fender and Rack Mounts
Suspension Fork
Marin Full Carbon w/ Taper Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra
Cassette
Shimano 10-Speed, 11-34T
Crank
FSA Omega MegaExo, 50/34T
Bottom Bracket
FSA MegaExo
Chain
KMC X10
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 19mm Inner, Disc Specific
Spokes
14g Black Stainless Steel
Tires
WTB, Riddler Comp, 700Cx37, Wire Bead
Brakes
Brakes
Shimano BR-RS405 Hydraulic
Brake Levers
Shimano Hydraulic w/ Integrated Shifters
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Comfort Tape
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.55 mm | 1.53 mm | 1.54 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 583 mm | 591 mm | 585 mm | 590 mm | 599 mm | 620 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 59 mm | 75 mm | 88 mm | 89 mm | 100 mm | 89 mm |
| Stack | 502 mm | 566 mm | 577 mm | 593.5 mm | 612.4 mm | 622 mm |
| Reach | 364.5 mm | 365 mm | 377 mm | 386.2 mm | 400.4 mm | 406.5 mm |
| Top Tube Length | 517 mm | 527 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm | 200 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 994 mm | 1002 mm | 995 mm | 1001 mm | 1010 mm | 1031 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 723 mm | 743 mm | 760 mm | 779 mm | 798 mm | 814 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Nicasio 2 belongs to the Marin Nicasio model. There are 25 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Marin Nicasio 2019 is the cheapest bike model and costs 759$. Marin Nicasio Ridge 2019 is the most expensive one and costs 2599$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2019 for 1499$. Comparing the average cost of a Gravel bike to this one, you will see that Nicasio 2 price is 64.24% lower.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
As for the wheels, Marin Nicasio 2 2019, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Nicasio 2 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
