Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Double Butted CrMo Beyond Road, 700C Wheels, Beyond Road Geometry, Fender and Rack Mounts, Disc Mount
Suspension Fork
CrMo, Fender and Rack Eyelets, IS Disc Mount
Drivetrain
Rear Derailleur
Shimano Claris 8-Speed
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris 2x8-Speed
Cassette
SunRace 8-Speed, 11-32T
Crank
FSA Tempo Compact, 50/34T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 19mm Inner, Disc Specific
Spokes
14g Black Stainless Steel
Tires
Vee Tire, Apache Chief, 700Cx30, Wire Bead
Brakes
Brakes
Promax Render R Road Mechanical Disc, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Comfort Tape
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.5 mm | 1.53 mm | 1.51 mm | 1.53 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 583 mm | 591 mm | 585 mm | 590 mm | 599 mm | 620 mm | 629 mm |
| Rake | 57 mm | 57 mm | 57 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 63 mm | 75 mm | 69 mm | 63 mm | 63 mm | 63 mm |
| Stack | 540.57 mm | 547.26 mm | 561.4 mm | 580.52 mm | 596.64 mm | 615.72 mm | 625.25 mm |
| Reach | 355.75 mm | 365.8 mm | 366.48 mm | 384.42 mm | 390.42 mm | 404.59 mm | 410.75 mm |
| Top Tube Length | 504 mm | 521 mm | 531 mm | 551 mm | 571 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm | 200 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 998 mm | 1006 mm | 999 mm | 1005 mm | 1014 mm | 1035 mm | 1044 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 703 mm | 727 mm | 747 mm | 764 mm | 783 mm | 802 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Nicasio is a Marin Nicasio model. 25 bikes variations carry this model name so far. You can easily view all of the Marin Nicasio bikes models from 2020, here.
Model range prices
The most economical model, the Marin Nicasio 1 2020 has a starting price of 759$. Marin Nicasio Ridge 2020 on the other hand is the most expensive at 2699$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 799$. Comparing the average cost of a Gravel bike to this one, you will see that Nicasio price is 208.14% lower.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When it comes to wheels, the Nicasio bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Nicasio has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
