Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset microSHIFT Advent, FSA -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Double Butted CrMo Beyond Road, 700C Wheels, Beyond Road Geometry, Fender and Rack Mounts, Disc Mount
Suspension Fork
CrMo, Fender and Rack Eyelets, IS Disc Mount
Drivetrain
Rear Derailleur
MicroSHIFT Advent, 1x9 w/ Clutch Mech
Front Derailleur
-
Shift Levers
MicroSHIFT Advent, 1x9 Specific
Cassette
SunRace 9-Speed, 11-46T
Crank
FSA Tempo Compact, Narrow-Wide, 42T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 25mm Inner, Disc Specific
Spokes
14g Black Stainless Steel
Tires
WTB Horizon, 650Bx47mm
Brakes
Brakes
Tektro Road Mechanical Disc, 160mm Rotor
Brake Levers
MicroSHIFT Advent
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Comfort Tape
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.5 mm | 1.53 mm | 1.51 mm | 1.53 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 583 mm | 591 mm | 585 mm | 590 mm | 599 mm | 620 mm | 629 mm |
| Rake | 57 mm | 57 mm | 57 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 59 mm | 56 mm | 68 mm | 63 mm | 57 mm | 57 mm | 57 mm |
| Stack | 540.57 mm | 547.26 mm | 561.4 mm | 580.52 mm | 596.64 mm | 615.72 mm | 625.25 mm |
| Reach | 355.75 mm | 365.8 mm | 366.48 mm | 384.42 mm | 390.42 mm | 404.59 mm | 410.75 mm |
| Top Tube Length | 504 mm | 521 mm | 531 mm | 551 mm | 571 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm | 200 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 998 mm | 1006 mm | 999 mm | 1005 mm | 1014 mm | 1035 mm | 1044 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 703 mm | 727 mm | 747 mm | 764 mm | 783 mm | 802 mm | 818 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
Model Overview
Nicasio + completes the Marin Nicasio model. 25 bikes variations carry this model name so far. Take a sneak peek at all Marin Nicasio bikes models from 2020, by clicking here.
Model range prices
Marin Nicasio 1 2020 is the most economical model, with a starting price of 759$. Marin Nicasio Ridge 2020 on the other hand costs 2699$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Marin Nicasio + price was 899$. Doing a quick comparison, we notice that Nicasio + price is 173.86% smaller than the average cost of a Gravel bike.
Nicasio + components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
When leaving the production line, the Nicasio + model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Nicasio + comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
