Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alfine -
Suspension Rigid -
Drivetrain Belt Drive, IGH -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
149cm - 156cm
SM
153cm - 167cm
MD
164cm - 177cm
LG
174cm - 187cm
XL
184cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 4 Commute, 6061 Aluminum, 700C Wheels, Sliding Dropouts, Tapered Head Tube, Internal Cable Routing, Belt Drive Compatible, Flat-Mount Disc, Fender, Rack, and Integrated Kickstand Mounts
Suspension Fork
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Shift Levers
Shimano Alfine 1x11-Speed
Crank
Shimano Alfine Hollowtech II, Gates Carbon Drive CDX 50T, Ring Guard
Bottom Bracket
Shimano Hollowtech II
Pedals
Commute Platform
Wheels
Front Hub
Shimano Alfine Dynamo 6V-3W, Centerlock Disc
Rear Hub
Shimano Alfine 11-Speed Internally Geared Hub, Centerlock Disc
Rims
Marin Aluminum Double Wall, 21mm Inner, 30mm Tall, Tubeless-Compatible, Disc Specific
Spokes
14g Black Stainless Steel
Tires
Continental Sport Contact II, 700Cx32, Puncture Protection, Reflective Sidewall, Wire Bead
Brakes
Brakes
Shimano U300 Flat-Mount Hydraulic Disc, 160mm Rotor
Brake Levers
Shimano Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Alloy Flat Top Riser
Grips
Marin Ergonomic Locking
Headset
FSA Orbit CE, Sealed Cartridge Bearings
Seat
Saddle
Marin Fitness Elite
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.47 mm | 1.48 mm | 1.5 mm | 1.52 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 591 mm | 606 mm | 621 mm | 636 mm | 656 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 63 mm | 63 mm | 63 mm | 63 mm |
| Stack | 555.89 mm | 574.97 mm | 594.04 mm | 613.11 mm | 641.73 mm |
| Reach | 382.74 mm | 392.09 mm | 401.44 mm | 409.94 mm | 421.19 mm |
| Top Tube Length | 548 mm | 563 mm | 578 mm | 598 mm | 618 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm | 520.7 mm | 558.8 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 135 mm | 155 mm | 175 mm | 195 mm | 225 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1015 mm | 1030 mm | 1046 mm | 1060 mm | 1081 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 657 mm | 703 mm | 748 mm | 781 mm | 817 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 153 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 156 cm | 167 cm | 177 cm | 187 cm | 190 cm |
Model Overview
Presidio 4 DLX completes the Marin Presidio model. There are 18 bikes that carry this model name. Take a sneak peek at all Marin Presidio bikes models from 2020, by clicking here.
Model range prices
Marin Presidio 1 2020 is the cheapest bike model and costs 679$. Marin Presidio 4 DLX 2020 is the most expensive one and costs 2349$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Commuter bikes average price
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Marin released this model in 2020, its price was 2349$. In conclusion, this bike price is 208.27% higher than the price of the average Commuter bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Presidio 4 DLX components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The Presidio 4 DLX 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Presidio 4 DLX has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Presidio 4 DLX comes in 5 sizes, that range from 149 cm – 190 cm (4.89 ft – 6.23 ft). In conclusion, finding one for you shouldn’t be a problem.
