Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 130mm -
Travel Rear 130mm -
Fork X-Fusion VELVET
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
137cm - 157cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All New Series 3 6061 Aluminum Frame, 26" Wheels, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB
Suspension Fork
X-Fusion Velvet RLC 26", 130mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle
Drivetrain
Rear Derailleur
Shimano Deore, 11-Speed, SGS
Front Derailleur
-
Shift Levers
Shimano Deore, 11-Speed, SL-5100R
Cassette
SunRace, 11-Speed, 11-51T, ED Black
Crank
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing, 170mm Length
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X-11 Silver and Black
Pedals
-
Wheels
Front Hub
Forged Alloy, 100x15mm, Centerlock Disc, 32H
Rear Hub
Forged Alloy, 135mm, Quad Sealed Bearings, Centerlock Disc, 32H
Rims
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific
Tires
Vee Tire Co. Flow Snap 26x2.4", Tackee Compound, Wire Bead
Brakes
Brakes
Hydraulic Disc
Brake Levers
Tektro HDM-280
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 720mm Width, 4º Up, 9º Back
Grips
Marin Dual Density
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.415 mm |
| Bottom Bracket Height | 308.5 mm |
| Front Center | 664 mm |
| Rake | 42 mm |
| Trail | 112 mm |
| Stack | 537.57 mm |
| Reach | 380 mm |
| Top Tube Length | 515.17 mm |
| Seat Tube Angle | 76 ° |
| Seat Tube Length | 315 mm |
| Head Tube Angle | 65.5 ° |
| Head Tube Length | 95 mm |
| Chainstay Length | 425 mm |
| Wheelbase | 1089 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 614 mm |
| Wheels | 26" |
| Rider Min Height | 137 cm |
| Rider Max Height | 157 cm |
About this model
Rift Zone 26″ completes the Marin Rift model. Marin launched 72 bikes of this model so far. You can easily view all of the Marin Rift bikes models from 2023, here.
Model range prices
Marin Rift Zone Jr 26″ 2023 is the most economical model, with a starting price of 1699$. Marin Rift Zone 29″ Carbon XR 2023 on the other hand costs 4859$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Marin released this model in 2023, its price was 1799$. Comparing the average cost of a Trail bike to this one, you will see that Rift Zone 26″ price is 53.53% lower.
Overview of components
Fork
This bike has the X-Fusion VELVET fork installed. The fork’s travel is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Rift Zone 26″ bike is equipped with the 26″ aluminum model. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rift Zone 26″ has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Marin Rift Zone 26″ 2023 is available in one size only. In conclusion, double-check its size to make sure it’s a good fit for you.
