Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork X-Fusion SLIDE
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, 29” Wheels, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs
Suspension Fork
X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 44mm Offset
Rear Shock
X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom
Drivetrain
Rear Derailleur
Shimano Deore, 11-Speed, SGS
Front Derailleur
-
Shift Levers
Shimano Deore, 11-Speed, SL-5100R
Cassette
Sunrace, 11-Speed, 11-51T, ED Black
Crank
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearing
Chain
KMC X-11 Silver and Black
Pedals
-
Wheels
Front Hub
Forged Alloy, 110x15mm, Sealed Cartridge Bearing, 32H
Rear Hub
Forged Alloy, Quad Sealed Cartridge Bearings, Alloy Axle, QR type, 141mm Width, 32H, Shimano Standard Freehub Body
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire Co. Snap WCE 29x2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless Compatible
Brakes
Brakes
Tektro HD-M280 Hydraulic, 180mm Rotor
Brake Levers
Tektro HD-M280
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Grips
Marin MTN, Closed End
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.36 mm | 1.31 mm | 1.24 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 742 mm | 777 mm | 807 mm | 838 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 132 mm | 125 mm | 125 mm | 125 mm |
| Stack | 630.6 mm | 635.2 mm | 644.3 mm | 648.8 mm |
| Reach | 442 mm | 467 mm | 492 mm | 522 mm |
| Top Tube Length | 586 mm | 612 mm | 639.1 mm | 670.2 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 390 mm | 400 mm | 425 mm | 430 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 110 mm | 115 mm | 125 mm | 130 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1177 mm | 1212 mm | 1241 mm | 1273 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 697 mm | 698 mm | 708 mm | 707 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 184 cm |
| Rider Max Height | 169 cm | 179 cm | 187 cm | 193 cm |
About this model
Rift Zone 29″ 1 belongs to the Marin Rift model. Marin launched 72 bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Marin Rift Zone Jr 24″ 2024 is the most affordable bike of this model and has a price of 1699$. On the other hand, Marin Rift Zone 29″ 2 2024, is the most expensive and costs 2299$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2024 and its price was 1699$. In conclusion, this bike price is 62.57% smaller than the price of the average Trail bike.
Overview of components
Fork
The Rift Zone 29″ 1 comes factory-installed with the X-Fusion SLIDE fork. This has a travel range of 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Marin Rift Zone 29″ 1 bike has the X-Fusion O2 Pro R model installed, and has a travel of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the Rift Zone 29″ 1 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Rift Zone 29″ 1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Marin Rift Zone 29″ 1 bike has 4 sizes, in the range of 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, you won’t have a problem finding one that suits you.
