Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 120mm -
Travel Rear 120mm -
Fork X Fusion
-
Groupset Deore, microSHIFT -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
124cm - 144cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 24" Wheel with Clearance for 26", 120mm Travel, MultiTrac Suspension Platform, 135mm Open Dropout (Upgradeable to 142x12mm Thru-Axle), 73mm Threaded BB
Suspension Fork
X-Fusion Velvet RLC 26", 120mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle
Drivetrain
Rear Derailleur
Shimano Deore, 11 Speed, SGS
Front Derailleur
-
Shift Levers
Micro Shift, SLM895, 11-Speed
Cassette
SunRace 11-Speed, 11-46T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 32T Chainring, Direct Mount Type
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X-11 Silver and Black
Wheels
Front Hub
Forged Alloy, 100x15mm, 32H
Rear Hub
Forged Alloy, 135mm, Quad Sealed Bearings, 32H
Rims
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Tires
Vee Tire Co, Flow Snap 24”x2.4", Tackee Compound, Wire Bead
Brakes
Brake Levers
Shimano BL-MT201 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 720mm Width, 4º Up, 9º Back
Grips
Marin Dual Density
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.41 mm |
| Bottom Bracket Height | 305 mm |
| Front Center | 590 mm |
| Rake | 42 mm |
| Stack | 539.24 mm |
| Reach | 383 mm |
| Top Tube Length | 539 mm |
| Seat Tube Angle | 69 ° |
| Seat Tube Length | 335 mm |
| Head Tube Angle | 67.5 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 431 mm |
| Wheelbase | 1021 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 624 mm |
| Wheels | 24" |
| Rider Min Height | 124 cm |
| Rider Max Height | 144 cm |
Model Overview
Rift Zone Jr is part of the Marin Rift model. Marin launched 72 bikes of this model so far. You can easily view all of the Marin Rift bikes models from 2022, here.
Model range prices
Marin Rift Zone 29 1 2022 is the most affordable bike of this model and has a price of 1899$. On the other hand, Marin Rift Zone 29 Carbon XR 2022, is the most expensive and costs 4859$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Mountain bikes average price
Our math shows that the average cost of a dependable Mountain bike is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2022 and its price was 1899$. Comparing this to the average Mountain bike price, we see that the price is 208.28% more expensive.
Overview of components
Fork
Marin Rift Zone Jr 2022 bike is equipped with the X Fusion fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Rift Zone Jr bike is equipped with the 24″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rift Zone Jr has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
