Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 2 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
149cm - 157cm
MD
160cm - 169cm
LG
166cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Dual Sport, 6061 Aluminum, 700C Wheels, Women's Fit Geometry, Step Through Design, Disc Brake
Suspension Fork
SR Suntour NEX, 63mm Travel, Preload Adjustment
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano TY710
Shift Levers
Shimano EF500 Shifter/Brake Lever Combo, 2x7-Speed
Cassette
SunRace 7-Speed, 11-34T
Crank
Forged Alloy Crank, 46/30T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z-8.3
Pedals
Dual Sport Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall
Tires
Kenda Kahn, 700Cx40mm
Brakes
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy, 31.8mm Clamp
Handlebar
Marin Alloy Riser
Grips
Dual Density Ergonomic
Headset
FSA No.10-P
Seat
Saddle
Marin Women's Fitness Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.59 mm | 1.58 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 291 mm |
| Front Center | 616 mm | 615 mm | 625 mm |
| Rake | 41 mm | 41 mm | 41 mm |
| Trail | 80 mm | 80 mm | 80 mm |
| Stack | 586.99 mm | 596.41 mm | 605.85 mm |
| Reach | 380.43 mm | 375.94 mm | 382.26 mm |
| Top Tube Length | 554.9 mm | 558.9 mm | 568.1 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1052 mm | 1051 mm | 1060 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 622 mm | 668 mm | 713 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 160 cm | 166 cm |
| Rider Max Height | 157 cm | 169 cm | 177 cm |
About this model
San Anselmo DS1 completes the Marin San Anselmo model. Marin launched 27 bikes of this model so far. You can easily view all of the Marin San Anselmo bikes models from 2021, here.
Model range prices
Marin San Anselmo DS1 2021 is the most economical model, with a starting price of 579$. Marin San Anselmo DS2 2021 on the other hand costs 699$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Marin San Anselmo DS1 price was 579$. Comparing the average cost of a Hybrid bike to this one, you will see that San Anselmo DS1 price is 3.02% higher.
Overview of components
Fork
The San Anselmo DS1 comes factory-installed with the SunTour NEX fork. This has a travel range of 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the San Anselmo DS1 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The San Anselmo DS1 comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Marin San Anselmo DS1 bike has 3 sizes, in the range of 149 cm – 177 cm (4.89 ft – 5.81 ft). In short, it won’t be difficult to find the right one for you.
