Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Acera, Tourney -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
149cm - 157cm
MD
160cm - 169cm
LG
166cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Dual Sport, 6061 Aluminum, 700C Wheels, Women's Fit Geometry, Step Through Design, Disc Brake
Suspension Fork
SR Suntour NEX Disc HLO, 63mm Travel, Hydraulic Lockout, Preload Adjustment
Drivetrain
Rear Derailleur
Shimano Acera 8-Speed
Front Derailleur
Shimano FD-TY710
Shift Levers
Shimano RapidFire Plus 2x8
Cassette
SunRace 8-Speed, 11-34T
Crank
Forged Alloy Crank, 46/30T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z-8.3
Pedals
Dual Sport Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire, Rail, 700cx40mm, Wire Bead
Brakes
Brake Levers
Tektro Hydraulic
Cockpit
Stem
Marin Alloy, 31.8mm Clamp
Handlebar
Marin Alloy Riser
Grips
Marin Ergonomic Locking
Headset
FSA No.10-P
Seat
Saddle
Marin Women's Fitness Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.59 mm | 1.58 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 291 mm |
| Front Center | 616 mm | 615 mm | 625 mm |
| Rake | 41 mm | 41 mm | 41 mm |
| Trail | 80 mm | 80 mm | 80 mm |
| Stack | 586.99 mm | 596.41 mm | 605.85 mm |
| Reach | 380.43 mm | 375.94 mm | 382.26 mm |
| Top Tube Length | 554.9 mm | 558.9 mm | 568.1 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1052 mm | 1051 mm | 1060 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 622 mm | 668 mm | 713 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 160 cm | 166 cm |
| Rider Max Height | 157 cm | 169 cm | 177 cm |
Model Overview
San Anselmo DS2 is part of the Marin San Anselmo model. There are 27 bikes that carry this model name. You can easily view all of the Marin San Anselmo bikes models from 2021, here.
Model range prices
Marin San Anselmo DS1 2021 is the cheapest bike model and costs 579$. Marin San Anselmo DS2 2021 is the most expensive one and costs 699$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Marin San Anselmo DS2 price was 699$. Doing a quick comparison, we notice that San Anselmo DS2 price is 24.38% higher than the average cost of a Hybrid bike.
Overview of components
Fork
The fork installed on this bike is the SunTour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When leaving the production line, the San Anselmo DS2 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The San Anselmo DS2 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Marin San Anselmo DS2 bike has 3 sizes, in the range of 149 cm – 177 cm (4.89 ft – 5.81 ft). In conclusion, finding one for you shouldn’t be a problem.
