Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 167cm
MD
164cm - 174cm
LG
171cm - 182cm
XL
179cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, Double Butted Frame, 141mm Open Dropout, 73mm Threaded BB
Suspension Fork
SR Suntour XCM32 Boost 15x110mm Spacing, 120mm Travel, Lock Out, 27.5", Bolt-On Thru-Axle, 47mm Offset
Drivetrain
Rear Derailleur
MicroShift RD-M9195M, 9 Speed, With Clutch
Front Derailleur
-
Shift Levers
MicroShift SL-M9195-R, 1x9 with Bearings
Cassette
Sunrace, 9 Speed, 11-46T
Crank
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
Bottom Bracket
Sealed Cartridge Bearing, Square Taper
Chain
KMC X-9
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 110x15mm, Disc, 32H
Rear Hub
Forged Alloy, 141mm Width, Disc, 32H, Shimano Standard Freehub Body
Rims
Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H Tubeless Compatible
Tires
Vee Tire Co, Flow Snap, 27.5x2.6", MPC Compound, Wire Bead
Brakes
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Marin 3D Forged Alloy, 45mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Grips
Marin MTN, Closed End
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 724 mm | 749 mm | 773 mm | 795 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 115 mm | 115 mm | 115 mm | 115 mm |
| Stack | 588.1 mm | 592.7 mm | 601.7 mm | 606.3 mm |
| Reach | 424 mm | 446 mm | 466 mm | 486 mm |
| Top Tube Length | 581.1 mm | 604.3 mm | 626.7 mm | 647.9 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 385 mm | 430 mm | 475 mm | 515 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 125 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1146 mm | 1170 mm | 1195 mm | 1217 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 666 mm | 679 mm | 716 mm | 747 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 157 cm | 164 cm | 171 cm | 179 cm |
| Rider Max Height | 167 cm | 174 cm | 182 cm | 188 cm |
Model Overview
San Quentin 1 is a Marin San Quentin model. Marin launched 47 bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Marin San Quentin 20 2022 is the cheapest bike model and costs 749$. Marin San Quentin 3 2022 is the most expensive one and costs 2399$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 1099$. If we compare this with the average Trail bike cost we notice that the price is 151.32% lower.
Overview of components
Fork
Marin San Quentin 1 2022 bike is equipped with the SunTour XCM fork, and has 120mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the San Quentin 1 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The San Quentin 1 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 157 cm – 188 cm (5.15 ft – 6.17 ft). In short, you can easily find one that suits you.
