Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Super-Low Step Design, Comfort Control Geometry, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Straight Blade, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano TY700
Shift Levers
Shimano EF41, 3x7-Speed
Cassette
SunRace 7-Speed, 11-32T
Crank
Shimano FC-TY301, 42/34/24T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Marin Comfort Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Spokes
14g Stainless Steel
Tires
Vee Tire Co. Speedster, 27.5”x2.0”, Puncture Protection
Brakes
Brakes
Forged Alloy Linear Pull w/ Power Modulator
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Adjustable Height and Angle
Handlebar
Marin Alloy, 50mm Rise
Grips
Marin Ergonomic Locking
Headset
FSA, Threaded
Seat
Saddle
Marin Comfort
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 2.02 mm | 2.03 mm | 1.41 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm |
| Front Center | 579 mm | 593 mm | 607 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 87 mm | 87 mm | 9 mm |
| Stack | 625.73 mm | 644.34 mm | 458.3 mm |
| Reach | 309.96 mm | 316.68 mm | 325.46 mm |
| Top Tube Length | 589 mm | 604 mm | 619 mm |
| Seat Tube Angle | 66 ° | 66 ° | 66 ° |
| Seat Tube Length | 382 mm | 432 mm | 483 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 210 mm | 230 mm | 245 mm |
| Chainstay Length | 489 mm | 489 mm | 489 mm |
| Wheelbase | 1059 mm | 1073 mm | 1088 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 450 mm | 451 mm | 451 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Stinson ST is a Marin Stinson model. Marin released 34 bikes variations of this model so far. Take a sneak peek at all Marin Stinson bikes models from 2019, by clicking here.
Model range prices
Marin Stinson 7 ST 2019 is the cheapest bike model and costs 419$. Marin Stinson 2019 is the most expensive one and costs 469$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Comfort bikes average price
If you want to purchase a solid Comfort bike, it is important to know that the average cost is 360$. However, this doesn’t mean that if you spend less money on a Comfort bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 469$. If we compare this with the average Comfort bike cost we notice that the price is 30.28% more expensive.
Overview of components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The Stinson ST 2019 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stinson ST comes with Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Stinson ST comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
