Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 4 6061 Aluminum, 29" Wheels, Superlight Aluminum Frame, Post-Mount Rear Brake, Internal Shifter and Dropper Post Routing, 148x12mm Boost Thru-Axle
Suspension Fork
RockShox Judy Silver TK, 120mm Travel, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Stealth, 51mm Offset
Drivetrain
Rear Derailleur
Shimano Deore 12-Speed
Front Derailleur
-
Shift Levers
Shimano Deore 12-Speed
Cassette
SunRace 12-speed, 11-51
Crank
Forged Alloy 1x12, Hollow Spindle, Steel Narrow Wide 32T Chainring
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X12
Pedals
Nylon Platform
Wheels
Front Hub
Forged Aluminum, 110x15mm, Disc, 32H
Rear Hub
Forged Aluminum, 148x12mm, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Sleeve Joint, Disc Specific, Tubeless Compatible
Tires
Vee Tire Co. Rail Rocco XC, 29x2.3", Dual Control Compound, Folding Bead, Tubeless Ready
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano BL-MT201 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 42ACB, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.39 mm | 1.3 mm |
| Bottom Bracket Height | 319.75 mm | 319.75 mm | 319.75 mm | 319.75 mm |
| Front Center | 704 mm | 726 mm | 748 mm | 786 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 611.9 mm | 616.5 mm | 621.05 mm | 630.3 mm |
| Reach | 408 mm | 428 mm | 448 mm | 483 mm |
| Top Tube Length | 584 mm | 605.3 mm | 626.7 mm | 664.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 97 mm | 102 mm | 107 mm | 117 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1120 mm | 1142 mm | 1164 mm | 1203 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 676 mm | 705 mm | 751 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 169 cm | 177 cm | 184 cm | 190 cm |
Model Overview
Team Marin 1 is part of the Marin Team Marin model. Marin launched 10 bikes of this model so far. You can easily view all of the Marin Team Marin bikes models from 2023, here.
Model range prices
Marin Team Marin 1 2023 is the most affordable bike of this model and has a price of 1499$. On the other hand, Marin Team Marin 2 2023, is the most expensive and costs 2499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 1499$. Comparing the average cost of a Trail bike to this one, you will see that Team Marin 1 price is 84.26% lower.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The Team Marin 1 comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Team Marin 1 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Team Marin 1 comes in 4 sizes, that range from 160 cm – 190 cm (5.25 ft – 6.23 ft). In short, you can easily find one that suits you.
