Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Fox Float 34
-
Groupset SLX, FSA -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 4 6061 Aluminum, 29" Wheels, Superlight Aluminum Frame, Post-Mount Rear Brake, Internal Shifter and Dropper Post Routing, 148x12mm Boost Thru-Axle
Suspension Fork
Fox 34 StepCast, 120mm Travel, Alloy Tapered Steerer, Air Spring, 110x15mm Boost Spacing, Kabolt Thru-Axle, 44mm Offset
Drivetrain
Rear Derailleur
Shimano SLX 12-Speed
Front Derailleur
-
Shift Levers
Shimano SLX 12-Speed
Cassette
SunRace 12-speed, 11-51
Crank
FSA Grid, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, MegaExo Spindle, Boost Spacing
Bottom Bracket
Mega Exo 73mm BSA
Chain
KMC X12
Pedals
Nylon Platform
Wheels
Front Hub
Forged Aluminum, 110x15mm, Disc, 32H
Rear Hub
Forged Aluminum, 148x12mm, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Sleeve Joint, Disc Specific, Tubeless Compatible
Tires
Maxxis Rekon Race, 29x2.35", Folding Bead, Tubeless Ready
Brakes
Brakes
Hydraulic Disc
Brake Levers
TRP G-Spec FMR Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 42ACB, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
TranzX Dropper Post, YSP23 w/ 1x Remote, Size S 125mm Travel, All Other Sizes: 150mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.39 mm | 1.3 mm |
| Bottom Bracket Height | 319.75 mm | 319.75 mm | 319.75 mm | 319.75 mm |
| Front Center | 704 mm | 726 mm | 748 mm | 786 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 611.9 mm | 616.5 mm | 621.05 mm | 630.3 mm |
| Reach | 408 mm | 428 mm | 448 mm | 483 mm |
| Top Tube Length | 584 mm | 605.3 mm | 626.7 mm | 664.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 97 mm | 102 mm | 107 mm | 117 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1120 mm | 1142 mm | 1164 mm | 1203 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 676 mm | 705 mm | 751 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 169 cm | 177 cm | 184 cm | 190 cm |
About this model
Team Marin 2 belongs to the Marin Team Marin model. Marin released 10 bikes variations of this model so far. Take a sneak peek at all Marin Team Marin bikes models from 2023, by clicking here.
Model range prices
Marin Team Marin 1 2023 is the most affordable bike of this model and has a price of 1499$. On the other hand, Marin Team Marin 2 2023, is the most expensive and costs 2499$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Marin released this model in 2023, its price was 2499$. In conclusion, this bike price is 10.52% lower than the price of the average Trail bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The Fox Float 34 is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
As for the wheels, Marin Team Marin 2 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Team Marin 2 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Team Marin 2 comes in 4 sizes, that range from 160 cm – 190 cm (5.25 ft – 6.23 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Team Marin 2. Therefore, climbing or descending will be a breeze.
