Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
152cm - 164cm
XS
152cm - 164cm
SM
161cm - 172cm
SM
161cm - 172cm
MD
169cm - 179cm
MD
169cm - 179cm
LG
176cm - 182cm
LG
176cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, Women’s SpecificFrame, 27.5” Wheels, 68mm BB shell, 135mm Forged Dropouts, IS Seatstay Disc Mounts
Suspension Fork
SR Suntour XCM-DS 27.5”, 100mm Travel, Custom Coil Spring
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano FD-TX500
Shift Levers
Shimano Tourney 3x7-Speed
Cassette
SunRace 7-Speed, 11-34T
Crank
Shimano FC-TY301, 42/34/24T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 32H
Rear Hub
Forged Alloy, 32H
Rims
Marin, Double Wall Alloy, 25mm Inner, Disc Specific Profile
Spokes
15g Black Stainless Steel
Tires
Mountain Tire, 27.5”x2.1"
Brakes
Brakes
Tektro MD280 Mechanical Disc, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy, 70mm
Handlebar
Marin Riser, 25mm Rise, 680mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.42 mm | 1.43 mm | 1.38 mm | 1.39 mm | 1.34 mm | 1.34 mm | 1.3 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 651 mm | 673 mm | 666 mm | 688 mm | 684 mm | 706 mm | 704 mm | 726 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 89 mm | 96 mm | 89 mm | 96 mm | 89 mm | 96 mm | 89 mm | 96 mm |
| Stack | 581.04 mm | 576.56 mm | 585.71 mm | 581.19 mm | 590.38 mm | 585.83 mm | 595.05 mm | 590.46 mm |
| Reach | 394.75 mm | 407.1 mm | 408.32 mm | 420.77 mm | 423.89 mm | 436.44 mm | 442.46 mm | 455.11 mm |
| Top Tube Length | 573 mm | 573 mm | 588 mm | 588 mm | 605 mm | 605 mm | 625 mm | 625 mm |
| Seat Tube Angle | 73 ° | 74 ° | 73 ° | 74 ° | 73 ° | 74 ° | 73 ° | 74 ° |
| Seat Tube Length | 330 mm | 330 mm | 381 mm | 381 mm | 431 mm | 431 mm | 482 mm | 482 mm |
| Head Tube Angle | 69 ° | 68 ° | 69 ° | 68 ° | 69 ° | 68 ° | 69 ° | 68 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm | 105 mm | 110 mm | 110 mm | 115 mm | 115 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1074 mm | 1096 mm | 1089 mm | 1111 mm | 1107 mm | 1129 mm | 1127 mm | 1149 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 614 mm | 613 mm | 654 mm | 650 | 696 mm | 691 mm | 737 mm | 733 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 152 cm | 161 cm | 161 cm | 169 cm | 169 cm | 176 cm | 176 cm |
| Rider Max Height | 164 cm | 164 cm | 172 cm | 172 cm | 179 cm | 179 cm | 182 cm | 182 cm |
Model Overview
Wildcat Trail 1 completes the Marin Wildcat model. 31 bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Marin Wildcat Trail 1 2019 is the most economical model, with a starting price of 429$. Marin Wildcat Trail 5 2019 on the other hand costs 989$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 429$. If we compare this with the average Crosscountry bike cost we notice that the price is 344.06% smaller.
Overview of components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on Wildcat Trail 1 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Wildcat Trail 1 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 8 sizes available for this model. Rider height can be anywhere between 152 cm – 182 cm (4.99 ft – 5.97 ft). In conclusion, it won’t take much to find one that’s right for you.
