Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM HLO
-
Groupset Altus, microSHIFT -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 159cm
SM
156cm - 167cm
MD
164cm - 174cm
LG
171cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, Women's Specific Frame, 27.5" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, IS Chainstay Disc Mount, Internal Housing Routing
Suspension Fork
SR Suntour XCM HLO, 120mm Travel, Hydraulic Lockout, 46mm Offset
Drivetrain
Rear Derailleur
Shimano Altus, 8-Speed
Front Derailleur
Altus Double
Shift Levers
MicroSHIFT TS39, 8-Speed, Thumb-Tap
Cassette
SunRace 8-Speed, 11-34T
Crank
Alloy Crank, Steel Chainrings, 36/22T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z51
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 32H
Rear Hub
Forged Alloy, 32H
Rims
Marin Aluminum Double Wall, 25mm Inner, Pinned Joint, Disc Specific
Tires
WTB Trailboss Comp, 27.5/29x2.25”, Wire Bead
Brakes
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Marin Alloy, 31.8mm Clamp, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 780mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.38 mm | 1.36 mm | 1.31 mm |
| Bottom Bracket Height | 307 mm | 307 mm | 307 mm | 307 mm |
| Front Center | 696 mm | 713 mm | 725 mm | 746 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 100 mm | 100 mm | 100 mm | 100 mm |
| Stack | 592.7 mm | 597.3 mm | 602 mm | 606.6 mm |
| Reach | 418 mm | 433 mm | 443 mm | 463 mm |
| Top Tube Length | 583 mm | 599 mm | 610.5 mm | 631.8 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 330 mm | 381 mm | 431 mm | 481 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1114 mm | 1131 mm | 1143 mm | 1165 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 619 mm | 656 mm | 701 mm | 741 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 156 cm | 164 cm | 171 cm |
| Rider Max Height | 159 cm | 167 cm | 174 cm | 180 cm |
Model Overview
Wildcat Trail 3 is a Marin Wildcat model. Marin launched 31 bikes of this model so far. You can easily view all of the Marin Wildcat bikes models from 2021, here.
Model range prices
The most economical model, the Marin Wildcat Trail 1 2021 has a starting price of 499$. Marin Wildcat Trail 5 2021 on the other hand is the most expensive at 1129$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2021 for 819$. Doing a quick comparison, we notice that Wildcat Trail 3 price is 237.24% smaller than the average cost of a Trail bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The SunTour XCM HLO is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Wildcat Trail 3 2021 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Marin Wildcat Trail 3 bike has 4 sizes, in the range of 147 cm – 180 cm (4.82 ft – 5.91 ft). In short, it won’t be difficult to find the right one for you.
