Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Lyrik
-
Groupset X01 Eagle, Truvativ Descendant Carbon -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Unidirectional Carbon Fiber Frame, Naild R3ACT – 2 Play Suspension Technology, 160mm Travel, 148mm Boost Rear Spacing, Naild 12-3-9 Locking Quick Release Thru-Axle
Suspension Fork
RockShox Lyrik RCT3 29”, 160mm Travel, Compression and Rebound Adjustment, Solo Air Spring, 110x15mm Boost Spacing, Maxle Ultimate, 51mm Offset
Rear Shock
RockShox Monarch R Debonair, High Volume Eyelet, 200x57mm, Rebound Adjustment, Custom Tune, 25.4mm x M8 Upper Hardware, Custom Lower Hardware
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-Speed
Front Derailleur
- - -
Shift Levers
SRAM X01 Eagle, 1x12-Speed
Cassette
SRAM XG-1295 12-Speed, 10-50T
Crank
Truvativ Descendant Carbon, Direct Mount 12-Speed 34T, Boost Spacing
Bottom Bracket
SRAM GXP BB92
Chain
SRAM X01 Eagle
Pedals
- - -
Wheels
Front Hub
Stan's NoTubes Neo Hub, 110x15mm, 6-Bolt Disc
Rear Hub
Stan's NoTubes Neo Hub, 148x12, XD Driver, 6-Bolt Disc
Rims
Stan's NoTubes Flow MK3, 29mm Inner, Welded Joint, BST Technology, Tubeless Ready
Spokes
Sapim Force Black 2.0/1.7/1.8mm
Tires
F: WTB Vigilante 29x2.3" R: WTB Breakout, 29x2.3", TCS Light/Fast, Tubeless Compatible
Brakes
Brakes
SRAM Guide RS Hydraulic Disc, 200mm Rotor
Brake Levers
SRAM Guide RS Hydraulic
Cockpit
Stem
Deity Copperhead Stem, 35mm
Handlebar
Deity Blacklabel, 800mm Width, 25mm Rise, Custom Color
Grips
Marin Locking
Headset
FSA No 42/ACB, Sealed Cartridge Bearings, 1 1/8"x 1 1/2”
Seat
Saddle
WTB Volt Race
Seatpost
KS LEV SIO Dropper Post, Custom Offset Head, Southpaw Lever, Size S 120mm Travel, All Other Sizes: 150mm Travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.43 mm | 1.37 mm | 1.38 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 722 mm | 742 mm | 773 mm | 797 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 113 mm | 113 mm | 113 mm | 113 mm |
| Stack | 633.5 mm | 633.5 mm | 642.8 mm | 665.6 mm |
| Reach | 422 mm | 442 mm | 469.2 mm | 482.8 mm |
| Top Tube Length | 582 mm | 602 mm | 627 mm | 644.6 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 390 mm | 420 mm | 465 mm | 525 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 125 mm |
| Chainstay Length | 442 mm | 442 mm | 442 mm | 442 mm |
| Wheelbase | 1161 mm | 1181 mm | 1213 mm | 1236 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm |
| Standover Height | 708 mm | 718 mm | 761 mm | 807 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 193 cm |
About this model
Wolf Ridge 9 is a Marin Wolf model. There are 12 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Marin Wolf Ridge 8 2019 is the cheapest bike model and costs 5299$. Marin Wolf Ridge Pro 2019 is the most expensive one and costs 8899$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6799$. In conclusion, this bike price is 88.91% higher than the price of the average Enduro bike.
Wolf Ridge 9 components
Fork
This bike has the RockShox Lyrik fork installed. The fork’s travel is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is RockShox Monarch R Debonair, with a travel distance of 160mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the Wolf Ridge 9 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Wolf Ridge 9 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Marin Wolf Ridge 9 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
