Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset microSHIFT, microSHIFT Advent X -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Brunello gravel | Smooth welded double-butted aluminum | 1.125 - 1.5" integrated head tube | BB86 bottom bracket | Flat-mount disc brake | Replaceable derailleur hanger | Internal dropper post compatible | 12 x 142mm thru-axle
Suspension Fork
Brunello gravel | MC-9 carbon construction | Carbon 1.125 - 1.5" tapered steer tube | Flat-mount disc | Fender mounts | 12 x 100mm thru-axle
Drivetrain
Rear Derailleur
microSHIFT RD-R43M 10s
Front Derailleur
microSHIFT FD-R712 | Band-type | ? 31.8mm clamp
Shift Levers
microSHIFT ADVENT X
Cassette
Sunrace CSMS1 | 10-spd | 11-34T
Crank
Brev. M All-Road 9/10s | 46/30T chainrings | 47-51cm : 170mm, 54-56cm : 172.5mm, 58-60cm : 175mm
Bottom Bracket
BB86 for 24mm spindle
Chain
KMC X10
Pedals
--
Wheels
Front Hub
Brev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-bolt | 28H
Rear Hub
Brev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-bolt | 28H
Rims
Brev M. 700c Performance Gravel Disc | Depth: 23mm, Width (internal): 21mm | 28H | Double wall | Tubeless compatible
Tires
Hutchinson Overide | 700x38c | Bi-compound | Folding
Brakes
Brakes
Rever MCX2 disc | Flat mount | Dual piston | 6-bolt rotors, 160mm
Brake Levers
microSHIFT SB-R502
Cockpit
Stem
Brev M. Gravel Variable Rise | 3D forged alloy | -6/-12° drop | 47cm: 90mm, 51-54cm: 100mm, 56-58cm: 110mm, 60cm: 120mm
Handlebar
Brev M. alloy all-road bend | ? 31.8mm | 120mm drop | 75mm reach | 47cm: 40cm, 51-56cm: 42cm, 58-60cm: 44cm
Headset
FSA 42E 1.5" tapered
Seat
Saddle
Masi Gravel Performance
Seatpost
Brev M. Alloy | ? 27.2mm x 330mm | 5mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.45 mm | 1.47 mm | 1.51 mm | 1.54 mm |
| Bottom Bracket Height | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm | 275 mm |
| Front Center | 597 mm | 605 mm | 612 mm | 619 mm | 626 mm | 635 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 67 mm | 67 mm | 66 mm | 65 mm | 66 mm | 66 mm |
| Stack | 557 mm | 565 mm | 586 mm | 600 mm | 616 mm | 635 mm |
| Reach | 394 mm | 400 mm | 405 mm | 407 mm | 409 mm | 412 mm |
| Top Tube Length | 547 mm | 555 mm | 570 mm | 580 mm | 587 mm | 595 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.7 ° | 73.7 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 570 mm |
| Head Tube Angle | 71.8 ° | 71.8 ° | 72.2 ° | 72.2 ° | 72.2 ° | 72.2 ° |
| Head Tube Length | 114.5 mm | 123 mm | 144 mm | 158.5 mm | 175 mm | 195.5 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1017 mm | 1025 mm | 1032 mm | 1039 mm | 1046 mm | 1055 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 739 mm | 768 mm | 794 mm | 813 mm | 832 mm | 857 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Brunello R10 belongs to the Masi Brunello model. Masi launched 7 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Masi Brunello FB Nove 2022 is the most economical model, with a starting price of 1149$. Masi Brunello ADX 2022 on the other hand costs 1699$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Masi released this model in 2022, its price was 1499$. In conclusion, this bike price is 64.24% lower than the price of the average Gravel bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When leaving the production line, the Brunello R10 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Masi Brunello R10 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
