Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
47cm
152cm - 168cm
51cm
166cm - 174cm
54cm
172cm - 180cm
56cm
177cm - 186cm
58cm
183cm - 192cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Masi Race Tuned Carbon MC9 Carbon, Di2 Compatible, BB86, Internal Routing, 1.5" Tapered Headtube & Direct Mount Brakes
Suspension Fork
Masi Race Tuned Carbon MC8 Tapered Full Carbon Fork, Direct Mount Brakes
Drivetrain
Rear Derailleur
Shimano 105 R5800
Front Derailleur
Shimano 105 R5801
Shift Levers
Shimano 105 R5800
Cassette
Shimano CS5800 11-28t 11-spd
Crank
Praxis Works Alba M30 52/36t
Bottom Bracket
Praxis Works M30 by Enduro
Chain
KMC X11
Pedals
N/A
Wheels
Rims
Shimano RS010
Tires
Kenda Valkyrie Pro Tubeless 700x25mm
Brakes
Brakes
Shimano 105 BR5010 Direct Mount
Brake Levers
Shimano 105 R5800
Cockpit
Stem
Brev. M 3D Forged Alloy Flip Flop
Handlebar
Brev. M Compact Bend Alloy
Headset
Masi by Token 1.5" Tapered, sealed bearing
Seat
Saddle
Masi Corsa Comp
Seatpost
Brev. M 3D Forged Alloy, 27.2 x 300mm, 25mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.37 mm | 1.39 mm | 1.42 mm | 1.41 mm | 1.42 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 569 mm | 575 mm | 586 mm | 594 mm | 618 mm | 633 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 59 mm | 56 mm | 55 mm | 58 mm | 58 mm |
| Stack | 504 mm | 525 mm | 545 mm | 567 mm | 584 mm | 603 mm |
| Reach | 378 mm | 382 mm | 391 mm | 400 mm | 415 mm | 424 mm |
| Top Tube Length | 522 mm | 532 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 966 mm | 972 mm | 983 mm | 991 mm | 1016 mm | 1031 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 714 mm | 746 mm | 766 mm | 799 mm | 819 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 172 cm | 177 cm | 183 cm | 187 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 196 cm |
About this model
Evoluzione 105 is a Masi Evoluzione model. Masi launched 16 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Masi Evoluzione 105 2018 is the cheapest bike model and costs 2339$. Masi Evoluzione Dura Ace 2018 is the most expensive one and costs 6199$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2339$. Doing a quick comparison, we notice that Evoluzione 105 price is 43.22% smaller than the average cost of a Race bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Evoluzione 105 components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The Evoluzione 105 2018 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Masi Evoluzione 105 bike has 6 sizes, in the range of 152 cm – 196 cm (4.99 ft – 6.43 ft). In short, you can easily find one that suits you.
