Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
47cm
152cm - 168cm
51cm
166cm - 174cm
54cm
172cm - 180cm
56cm
177cm - 186cm
58cm
183cm - 192cm
61cm
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Masi Race Tuned Carbon MCX TeXtreme Carbon, Di2 Compatible, BB86, Internal Routing, 1.5" Tapered Headtube & Direct Mount Brakes
Suspension Fork
Masi Race Tuned Carbon MCX TeXtreme Tapered Full Carbon Fork, Direct Mount Brakes
Drivetrain
Rear Derailleur
Shimano Dura Ace R9100
Front Derailleur
Shimano Dura Ace R9100
Shift Levers
Shimano Dura Ace R9100
Cassette
Shimano Dura Ace R9100 11-28t 11-spd
Crank
Rotor 3D+ 52/36t
Bottom Bracket
Enduro Dual-Row Bearing BB86 for Masi
Chain
KMC X11 DLC Black
Pedals
N/A
Wheels
Front Hub
3T Orbis C35 Team, 20/24h
Rear Hub
3T Orbis C35 Team, 20/24h
Rims
3T Orbis C35 Team Carbon Clincher, Tubeless Compatible
Tires
Kenda Valkyrie Pro Tubeless 700x25mm
Brakes
Brakes
Shimano Dura Ace BR9110 Direct Mount
Brake Levers
Shimano Dura Ace R9100
Cockpit
Stem
3T ARX II
Handlebar
3T Ergonova Team Stealth Carbon
Headset
Masi by Token 1.5" Tapered, sealed bearing
Seat
Saddle
Prologo Nago Evo saddle w/NACK carbon rails
Seatpost
3T Zero Carbon, 27.2mm, adjustable offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.37 mm | 1.39 mm | 1.42 mm | 1.41 mm | 1.42 mm |
| Bottom Bracket Height | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 569 mm | 575 mm | 586 mm | 594 mm | 618 mm | 633 mm |
| Rake | 45 mm | 45 mm | 45 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 59 mm | 56 mm | 55 mm | 58 mm | 58 mm |
| Stack | 504 mm | 525 mm | 545 mm | 567 mm | 584 mm | 603 mm |
| Reach | 378 mm | 382 mm | 391 mm | 400 mm | 415 mm | 424 mm |
| Top Tube Length | 522 mm | 532 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 966 mm | 972 mm | 983 mm | 991 mm | 1016 mm | 1031 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 714 mm | 746 mm | 766 mm | 799 mm | 819 mm | 844 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 166 cm | 172 cm | 177 cm | 183 cm | 187 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 196 cm |
Model Overview
Evoluzione Dura Ace belongs to the Masi Evoluzione model. Masi released 16 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
The most economical model, the Masi Evoluzione 105 2018 has a starting price of 2339$. Masi Evoluzione Dura Ace 2018 on the other hand is the most expensive at 6199$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6199$. Doing a quick comparison, we notice that Evoluzione Dura Ace price is 85.04% higher than the average cost of a Race bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Evoluzione Dura Ace are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Masi Evoluzione Dura Ace is equipped with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 152 cm – 196 cm (4.99 ft – 6.43 ft). In conclusion, you won’t have a problem finding one that suits you.
