Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Ultimate
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 170cm
MD
168cm - 180cm
LG
178cm - 188cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full UK construction, custom shaped and formed Dedacciai Zero/Uno & Reynolds steel tubeset.
Suspension Fork
RockShox SID Ultimate 120mm
Drivetrain
Shift Levers
Shimano Deore XT M8100
Cassette
Shimano Deore XT M8100 10-51T
Crank
Shimano Deore XT 32T M8100
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano Deore XT 12spd.
Wheels
Rims
Choice of HUNT MTB wheelsets.
Tires
Choice of Maxxis, Schwalbe and Vittoria.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Ritchey Trail WCS.
Handlebar
Renthal FatBar 2
Grips
Ergon GA2.
Headset
Deda EC/ZS44mm sealed bearing headset.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
PNW Loam 31.6 dropper post.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 722 mm | 751.9 mm | 775.8 mm | 803 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 117 mm | 117 mm | 117 mm | 117 mm |
| Stack | 605.3 mm | 614.4 mm | 623.5 mm | 632.7 mm |
| Reach | 421 mm | 446.2 mm | 466 mm | 489.3 mm |
| Top Tube Length | 572.7 mm | 601 mm | 623.4 mm | 649 mm |
| Seat Tube Angle | 75.2 ° | 75.12 ° | 75.11 ° | 75.37 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 505 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1146 mm | 1175 mm | 1199 mm | 1226 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 170 cm | 180 cm | 188 cm | 198 cm |
About this model
RAW Deore XT is part of the Mason Raw model. 6 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Mason RAW SLX 2022 is the most affordable bike of this model and has a price of 4616$. On the other hand, Mason RAW GX AXS 2022, is the most expensive and costs 5711$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Mason released this model in 2022, its price was 5103$. Comparing the average cost of a Trail bike to this one, you will see that RAW Deore XT price is 84.76% more expensive.
Overview of components
Fork
The RAW Deore XT comes factory-installed with the RockShox SID Ultimate fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on RAW Deore XT are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The RAW Deore XT has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Mason RAW Deore XT bike has 4 sizes, in the range of 162 cm – 198 cm (5.31 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Mason RAW Deore XT comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
