Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Ultimate
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 170cm
MD
168cm - 180cm
LG
178cm - 188cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full UK construction, custom shaped and formed Dedacciai Zero/Uno & Reynolds steel tubeset.
Suspension Fork
RockShox SID Ultimate 120mm
Drivetrain
Shift Levers
Shimano Deore XT M8100
Cassette
Shimano Deore XT M8100 10-51T
Crank
Shimano Deore XT 32T M8100
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano Deore XT 12spd.
Wheels
Rims
Choice of HUNT MTB wheelsets.
Tires
Choice of Maxxis, Schwalbe and Vittoria.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Ritchey Trail WCS.
Handlebar
Renthal FatBar 2
Grips
Ergon GA2.
Headset
Deda EC/ZS44mm sealed bearing headset.
Seat
Saddle
Fizik Terra Argo X3.
Seatpost
PNW Loam 31.6 dropper post.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 722 mm | 751.9 mm | 775.8 mm | 803 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 117 mm | 117 mm | 117 mm | 117 mm |
| Stack | 605.3 mm | 614.4 mm | 623.5 mm | 632.7 mm |
| Reach | 421 mm | 446.2 mm | 466 mm | 489.3 mm |
| Top Tube Length | 572.7 mm | 601 mm | 623.4 mm | 649 mm |
| Seat Tube Angle | 75.2 ° | 75.12 ° | 75.11 ° | 75.37 ° |
| Seat Tube Length | 395 mm | 430 mm | 470 mm | 505 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1146 mm | 1175 mm | 1199 mm | 1226 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 170 cm | 180 cm | 188 cm | 198 cm |
Model Overview
RAW Deore XT is part of the Mason Raw model. Mason released 6 bikes variations of this model so far. You can easily view all of the Mason Raw bikes models from 2023, here.
Model range prices
The most economical model, the Mason RAW SLX 2023 has a starting price of 4616$. Mason RAW GX AXS 2023 on the other hand is the most expensive at 5711$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5103$. Comparing this to the average Trail bike price, we see that the price is 84.76% higher.
Overview of components
Fork
This bike has the RockShox SID Ultimate fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, Mason RAW Deore XT 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The RAW Deore XT has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Mason RAW Deore XT bike has 4 sizes, in the range of 162 cm – 198 cm (5.31 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Mason model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
