Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BIG.NINE TFS III, material: aluminum, 29x2.25" max. wheelsize, 135x9mm axle standard, BSA bottom bracket standard, MUK 5 Hanger
Suspension Fork
Rock Shox Judy TK, Coil, 100mm suspension travel Lockout, 46mm fork offset, 29x2.25" max. wheelsize
Drivetrain
Rear Derailleur
Shimano RD-M370
Front Derailleur
Shimano FD-M2020-TS [2s]
Shift Levers
Shimano ST-EF505-2L / Shimano ST-EF505
Cassette
Shimano CS-HG200, 11-32 teeth, 9 speed
Crank
Shimano MT101-2, 36-22 teeth, 170 mm-S, 175 mm-M/XXL
Bottom Bracket
Shimano BB-UN100, Shimano FD-M2020-TS [2s]
Chain
KMC M99
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA CC, 17mm inner width, material: aluminium
Tires
MERIDA K1080, 29x2.2", wire
Brakes
Brakes
Power DS100
Disk Rotors
Shimano RT10, 160 mm
Cockpit
Stem
MERIDA CC, material: aluminium, 31.8mm diameter, 6° stem angle, 70 mm-S, 80 mm-M, 90 mm-L, 100 mm-XL, 110 mm-XXL
Handlebar
MERIDA CC, material: aluminium, 690mm width, 15mm rise
Headset
MERIDA M2345
Seat
Seatpost
MERIDA CC, material: aluminium, 30.9mm diameter, 15mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.56 mm | 1.53 mm | 1.51 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 657 mm | 677 mm | 698 mm | 719 mm |
| Rake | 46 mm | 45 mm | 46 mm | 46 mm |
| Trail | 87 mm | 88 mm | 87 mm | 87 mm |
| Stack | 624 mm | 638 mm | 652 mm | 666 mm |
| Reach | 394 mm | 410 mm | 425 mm | 441 mm |
| Top Tube Length | 586 mm | 606 mm | 626 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 560 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1086 mm | 1106 mm | 1127 mm | 1148 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 723 mm | 759 mm | 796 mm | 839 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
BIG NINE 60 is a Merida Big Nine model. Merida released 5 bikes variations of this model so far. You can easily view all of the Merida Big Nine bikes models from 2022, here.
Model range prices
Merida BIG NINE 20 2022 is the cheapest bike model and costs 851$. Merida BIG NINE 80 2022 is the most expensive one and costs 1216$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Merida released this model in 2022, its price was 973$. Comparing this to the average Crosscountry bike price, we see that the price is 95.79% smaller.
BIG NINE 60 components
Fork
The RockShox Judy is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the BIG NINE 60 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
