Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NX 1
-
Groupset CUES, Shimano -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CROSSWAY L TFS III, material: aluminium, 700x50C max. wheelsize, 135x9 mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour NX1, Coil, 63 mm suspension travel, Lockout, 700x50C max. wheelsize
Drivetrain
Rear Derailleur
Shimano CUES U6020 10S
Front Derailleur
Shimano CUES U6010
Shift Levers
Shimano CUES U6000
Cassette
Shimano LG300, 11-39 teeth, 10 speed
Crank
Shimano CUES U4010, 46-30 teeth, 170 mm-XXS/XS/S, 175 mm-M/XL
Bottom Bracket
BSA, threaded
Chain
Shimano LG500
Pedals
VP VPE-891
Wheels
Front Hub
Shimano QC300 / Shimano QC300-HM, 100x9 mm width front hub, 32 spoke holes, Centerlock, 135x9 mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano QC300 / Shimano QC300-HM, 100x9 mm width front hub, 32 spoke holes, Centerlock, 135x9 mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20 mm inner width, 17 mm height, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild, Rear: Maxxis Overdrive Excel, 700x40C, wire, reflective stripe, Silkshild
Brakes
Brakes
Shimano MT200, 2 piston
Cockpit
Stem
MERIDA COMP TK, material: aluminium, 31.8 mm diameter, adjustable, XXS/XS/S/M: 95 mm, L/XL: 110 mm
Handlebar
MERIDA COMP CC, material: aluminium, 660 mm width, 25 mm rise
Headset
MERIDA M2346 Neck
Seat
Saddle
MERIDA Cross Sport
Seatpost
MERIDA TK, 30.9 mm diameter, 10 mm setback, 45 mm seatpost suspension travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.602 mm | 1.606 mm | 1.617 mm |
| Front Center | 630 mm | 634 mm | 645 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 79 mm | 76 mm | 76 mm |
| Stack | 620 mm | 631 mm | 645 mm |
| Reach | 387 mm | 393 mm | 399 mm |
| Top Tube Length | 565 mm | 580 mm | 590 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 140 mm | 155 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1081 mm | 1085 mm | 1096 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 639 mm | 639 mm | 639 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
CROSSWAY L 300 belongs to the Merida Crossway model. Merida launched 220 bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Merida CROSSWAY 10-V 2024 is the cheapest bike model and costs 513$. Merida CROSSWAY L 100 2024 is the most expensive one and costs 706$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
The fork installed on this bike is the Suntour NX 1 model. The travel on this model is 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the CROSSWAY L 300 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The CROSSWAY L 300 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, it won’t take much to find one that’s right for you.
