Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 133mm -
Fork Suntour XCR Air
-
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Trendpower Internal Battery, 750Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eONE-FORTY LITE III, material: aluminium, 133mm suspension travel, 27.5x2.8" max. wheelsize, 148x12mm axle standard, intube
Suspension Fork
Suntour XCR34 LOR DS, Air Boost, 140mm, Tapered, 51mm fork offset, 29x2.4" max wheelsize
Rear Shock
SUNTOUR RS-EDGE-TR-LO-R8-M6, lockout
Drivetrain
Rear Derailleur
Shimano Deore RDM5120 10
Shift Levers
Shimano SL -MT500-IL / Shimano Deore M4100
Cassette
Shimano M4100, 11-46 teeth, 10 speed
Crank
Shimano CRE70-B, 34 teeth
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC e10s
Pedals
VP VPE-537
Wheels
Front Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock
Rear Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock
Rims
MERIDA COMP TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Tires
MAXXIS REKON, 29x2.4", wire, DUAL
Brakes
Brakes
Shimano M4204 / Shimano M4100, 4 piston, 2 piston
Cockpit
Handlebar
MERIDA EXPERT eTR, 780mm width, 20mm rise
Headset
MERIDA-8152
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP TR, 30.9mm diameter, 0mm setback, M 100mm travel seatpost - L/XL 125mm travel seatpost - XXL 150mm travel seatpost
Motor & Battery
Motor
Shimano EP6, 85Nm
Battery
Trendpower Internal Battery, 750Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 1.36 mm | 1.31 mm |
| Front Center | 744 mm | 766 mm | 788 mm | 810 mm |
| Rake | 47 mm | 47 mm | 49 mm | 48 mm |
| Trail | 112 mm | 112 mm | 109 mm | 110 mm |
| Stack | 625 mm | 629 mm | 633 mm | 638 mm |
| Reach | 428 mm | 448 mm | 467 mm | 487 mm |
| Top Tube Length | 579 mm | 601 mm | 622 mm | 643 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 415 mm | 430 mm | 450 mm | 470 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1180 mm | 1202 mm | 1224 mm | 1246 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 728 mm | 725 mm | 731 mm | 745 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
eONE-FORTY 475 (EP6) completes the Merida E Eone Forty model. There are 41 e-bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Merida eONE-FORTY 400 2023 is the cheapest e-bike model and costs 5054$. Merida eONE-FORTY 700 2023 is the most expensive one and costs 6881$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail e-bikes
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the Suntour XCR Air model. The travel on this model is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the SUNTOUR RS-EDGE-TR-LO-R8-M6 model, with a travel of 133mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Merida eONE-FORTY 475 (EP6) 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida eONE-FORTY 475 (EP6) is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
The Merida model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
