Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox Yari RC
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano E8010, 504Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
167cm - 183cm
LG
177cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eONE-SIXTY LITE, material: aluminium, 160mm suspension travel, 27.5" wheelsize, 148x12mm axle standard, external, max. 504 Wh
Suspension Fork
Rock Shox Yari RC, Air, 160mm suspension travel, Tapered, 51mm fork offset
Rear Shock
Rock Shox Super Deluxe Select+, platform
Drivetrain
Rear Derailleur
Shimano XT RDM8100 Shadow+
Shift Levers
Shimano SL -MT800-IL
Cassette
Shimano M7100, 10-51 teeth, 12 speed
Crank
Shimano CRE80-12-B, 34 teeth, Shimano FC-E8000
Bottom Bracket
included
Chain
CN-M7100
Wheels
Front Hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano SLX, 148x12mm width rear hub, 36 spoke holes, Centerlock
Rims
MERIDA EXPERT TP, 38mm inner width, material: aluminium, Tubeless ready (tubeless tape and valved not included)
Spokes
Black stainless
Tires
Maxxis DHR II, 27.5x2.6 ", fold, 3C EXO TR
Brakes
Brakes
Shimano SLX, 4 piston
Cockpit
Handlebar
MERIDA Expert eTR, material: aluminium, 780mm width, 20mm rise
Headset
FSA NO.57/55E neck
Seat
Saddle
MERIDA Expert CC, V-mount, incl. MERIDA minitool
Seatpost
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S 125mm travel seatpost - M/L 150mm travel seatpost - XL 170mm travel seatpost
Motor & Battery
Motor
Shimano E8000, 70Nm
Battery
Shimano E8010, 504Wh
Remote
Shimano SC-E7000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.43 mm | 1.41 mm | 1.39 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 735 mm | 763 mm | 791 mm | 819 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 99 mm | 99 mm | 99 mm | 99 mm |
| Stack | 601 mm | 619 mm | 637 mm | 656 mm |
| Reach | 413 mm | 433 mm | 453 mm | 473 mm |
| Top Tube Length | 576 mm | 601 mm | 627 mm | 651 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 410 mm | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1167 mm | 1195 mm | 1223 mm | 1251 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Standover Height | 717 mm | 720 mm | 750 mm | 782 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Max Height | 173 cm | 183 cm | 190 cm | cm |
About this model
eONE-SIXTY 800 SE is a Merida E Eone Sixty model. 43 e-bikes variations carry this model name so far. Take a sneak peek at all Merida E Eone Sixty e-bikes models from 2020, by clicking here.
Model range prices
Merida eONE-SIXTY 500 SE 2020 is the cheapest e-bike model and costs 4683$. Merida eONE-SIXTY 10K 2020 is the most expensive one and costs 11556$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Enduro e-bikes average weight
On a deeper look, we notice that the average weight of an Enduro e-bike is 23.42 kg (51.63 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 22.17 kg (48.88 lbs), Merida e-bike is a bit lighter than average. To sum up, it’s 5.64% lighter than the average weight of Enduro e-bikes.
eONE-SIXTY 800 SE components
Fork
This e-bike has the RockShox Yari RC fork installed. The fork’s travel is 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Merida eONE-SIXTY 800 SE e-bike has the Rock Shox Super Deluxe Select+ model installed, and has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Merida eONE-SIXTY 800 SE 2020, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The eONE-SIXTY 800 SE has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
Merida eONE-SIXTY 800 SE comes with a dropper post. Therefore, climbing or descending will be a breeze.
