Merida eSPRESSO URBAN 100 EQ 2022
2022 E-bike
Estimate price |
2,835$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio -
Suspension Hardtail -
Motor MAHLE 40Nm hub-drive -
Battery Mahle B1-D, 250Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eSPRESSO URBAN LITE
Suspension Fork
SR Suntour NEX E25, Coil, 63mm suspension travel, 700x52C max wheelsize
Drivetrain
Rear Derailleur
Shimano Alivio, SGS
Shift Levers
Shimano Alivio
Cassette
Shimano CS-HG201, 11-36 teeth, 9 speed
Crank
MERIDA COMP TK, 42 teeth, XS-165mm, S/M/L-170mm, XL-175mm
Bottom Bracket
EB2401 BSA 68mm
Chain
KMC e9S
Chain Guide
Custom MERIDA Chainguard
Wheels
Front Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TK, 20mm inner width, material: aluminium
Spokes
Black stainless
Tires
Continental Contact Urban, 622-50, wire, reflecting line
Brakes
Brakes
Shimano MT200, 2 piston
Brake Levers
attached to brake
Disk Rotors
Shimano SM-RT10 / Shimano SM-RT26, 180mm
Cockpit
Handlebar
MERIDA EXPERT TK, material: aluminium, 640mm width, 35mm rise
Seat
Saddle
MERIDA EXPERT TK, V-mount
Seatpost
MERIDA EXPERT, material: aluminium, 30.9mm diameter, 0mm setback
Motor & Battery
Motor
Mahle X35+ Hub Engine, 40Nm
Battery
Mahle B1-D, 250Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.76 mm | 1.71 mm | 1.67 mm | 1.64 mm | 1.62 mm |
| Front Center | 650 | 665 mm | 675 mm | 691 mm | 706 mm |
| Rake | 44 mm | 43 mm | 44 mm | 44 mm | 44 mm |
| Trail | 87 mm | 88 mm | 84 mm | 84 mm | 84 mm |
| Stack | 653 mm | 658 mm | 665 mm | 674 mm | 684 mm |
| Reach | 371 mm | 385 mm | 398 mm | 410 mm | 422 mm |
| Top Tube Length | 572 mm | 587 mm | 602 mm | 617 mm | 632 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm | 580 mm |
| Head Tube Angle | 69 ° | 69 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 170 mm | 175 mm | 180 mm | 190 mm | 200 mm |
| Chainstay Length | 467 mm | 467 mm | 467 mm | 467 mm | 467 mm |
| Wheelbase | 1108 mm | 1123 mm | 1133 mm | 1149 mm | 1164 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
eSPRESSO URBAN 100 EQ completes the Merida E Espresso model. There are 185 e-bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Merida eSPRESSO 300 SE EQ 2022 is the most economical model, with a starting price of 2483$. Merida eSPRESSO CC 675 EQ 2022 on the other hand costs 4866$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid e-bikes
According to our math, the average price for a trustworthy Hybrid e-bike is 2480$. However, you could also get a good Hybrid e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2022 for 2547$. If we compare this with the average Hybrid e-bike cost we notice that the price is 2.7% higher.
eSPRESSO URBAN 100 EQ components
Fork
Merida eSPRESSO URBAN 100 EQ 2022 e-bike is equipped with the Suntour NEX fork, and has 63mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on eSPRESSO URBAN 100 EQ are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
eSPRESSO URBAN 100 EQ comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
