Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 165mm -
Fork RockShox Yari RC
-
Groupset Deore, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-SIXTY LITE, 165mm suspension travel, material: aluminium, 27.5x2.6" max. wheelsize, 148x12mm axle standard, BB92 bottom bracket standard
Suspension Fork
Rock Shox Yari RC, Air, 170mm suspension travel, Tapered, 37mm fork offset, 27.5x2.8" max. wheelsize
Rear Shock
Rock Shox Deluxe Select+, platform
Drivetrain
Rear Derailleur
Shimano Deore M5100 Shadow+, SGS
Shift Levers
Shimano SL -MT500-IL
Cassette
Shimano Deore M5100, 11-51 teeth, 11 speed
Crank
Race Face Ride, 32 teeth, 170 mm-S up
Bottom Bracket
BB86/BB92, press-fit
Chain
KMC X11 NPBK
Wheels
Front Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock
Rear Hub
Shimano MT400-B, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Assegai, 27.5x2.5", fold, TR DD 3C MaxxGrip
Brakes
Brakes
Shimano Deore M6120, 4 piston
Cockpit
Handlebar
MERIDA EXPERT TR, material: aluminium, 780mm width, 20mm rise
Headset
FSA NO.57/55E neck
Seat
Saddle
MERIDA COMP CC
Seatpost
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 100mm travel seatpost - M: 125mm travel seatpost - L/XL: 150mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.451 mm | 1.361 mm | 1.293 mm | 1.259 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 727 mm | 759 mm | 793 mm | 817 mm |
| Rake | 42 mm | 42 mm | 36 mm | 42 mm |
| Trail | 117 mm | 117 mm | 124 mm | 117 mm |
| Stack | 595 mm | 599 mm | 613 mm | 617 mm |
| Reach | 410 mm | 440 mm | 474 mm | 490 mm |
| Top Tube Length | 559 mm | 591 mm | 630 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 430 mm | 470 mm | 490 mm |
| Head Tube Angle | 65.3 ° | 65.3 ° | 65.3 ° | 65.3 ° |
| Head Tube Length | 105 mm | 110 mm | 125 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1157 mm | 1189 mm | 1223 mm | 1247 mm |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm | 6 mm |
| Standover Height | 713 mm | 734 mm | 757 mm | 765 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
ONE-SIXTY 400 completes the Merida One Sixty model. There are 37 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Merida ONE-SIXTY 500 2023 is the most affordable bike of this model and has a price of 3345$. On the other hand, Merida ONE-SIXTY 10K 2023, is the most expensive and costs 10948$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Enduro bikes average weight
On a deeper look, we notice that the average weight of an Enduro bike is 14.27 kg (31.46 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Merida ONE-SIXTY 400 it’s weighing 15.42 kg (34 lbs). At this weight, is a bit heavier than average. To sum up, it’s 8.06% heavier than the average weight of Enduro bikes.
ONE-SIXTY 400 components
Fork
The RockShox Yari RC is included from the factory. It has a travel distance of 170mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The ONE-SIXTY 400 has a rear shock with a travel of 165mm. The model Rock Shox Deluxe Select+ is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The ONE-SIXTY 400 2023 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida ONE-SIXTY 400 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Merida ONE-SIXTY 400 comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
