Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 170mm -
Travel Rear 165mm -
Fork Marzocchi Bomber Z1
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-SIXTY CFA, 165mm suspension travel, material: carbon/aluminium, 27.5x2.6" max. wheelsize, 148x12mm axle standard, BB92 bottom bracket standard
Suspension Fork
Marzocchi Z1, Air, 170mm suspension travel, Tapered, 37mm fork offset, 27.5x2.8" max. wheelsize
Rear Shock
Fox Performance Float DPX2, platform
Drivetrain
Rear Derailleur
Shimano XT M8100 Shadow+, SGS
Shift Levers
Shimano SL -MT500-IL / Shimano Deore M6100
Cassette
Shimano Deore M6100, 10-51 teeth, 12 speed
Crank
Race Face Ride, 32 teeth, 170 mm-S up
Bottom Bracket
Race Face BB BB92– Ø24mm
Chain
KMC X12
Chain Guide
MRP 1X CS
Wheels
Front Hub
Shimano MT400-B / Shimano MT410-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano MT400-B / Shimano MT410-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TR, 27.5mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Assegai, 27.5x2.5", fold, TR DD 3C MaxxGrip
Brakes
Brakes
Shimano Deore M6120, 4 piston
Disk Rotors
Shimano RT30, 203 mm, 180 mm
Cockpit
Handlebar
MERIDA EXPERT TR, material: aluminium, 780mm width, 20mm rise
Headset
FSA NO.57/55E neck
Seat
Saddle
MERIDA COMP CC
Seatpost
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S: 125mm travel seatpost - M 150mm travel seatpost - L 170mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.427 mm | 1.351 mm | 1.293 mm |
| Bottom Bracket Height | 349 mm | 349 mm | 349 mm |
| Front Center | 736 mm | 771 mm | 807 mm |
| Rake | 47 mm | 48 mm | 48 mm |
| Trail | 112 mm | 111 mm | 111 mm |
| Stack | 592 mm | 601 mm | 614 mm |
| Reach | 415 mm | 445 mm | 475 mm |
| Top Tube Length | 563 mm | 597 mm | 632 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 400 mm | 430 mm | 470 mm |
| Head Tube Angle | 65.3 ° | 65.3 ° | 65.3 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1166 mm | 1201 mm | 1237 mm |
| Bottom Bracket Drop | 6 mm | 6 mm | 6 mm |
| Standover Height | 717 mm | 736 mm | 766 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
ONE-SIXTY 4000 is part of the Merida One Sixty model. Merida released 37 bikes variations of this model so far. Take a sneak peek at all Merida One Sixty bikes models from 2021, by clicking here.
Model range prices
Merida ONE-SIXTY 400 2021 is the most economical model, with a starting price of 2433$. Merida ONE-SIXTY 700 2021 on the other hand costs 3467$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Enduro bikes
Enduro bikes have an average weight of 14.27 kg (31.46 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Merida ONE-SIXTY 4000 it’s weighing 15.11 kg (33.31 lbs). At this weight, is a bit heavier than average. In short, the average Enduro bike weight is 5.89% lower than this one.
ONE-SIXTY 4000 components
Fork
The ONE-SIXTY 4000 comes factory-installed with the Marzocchi Bomber Z1 fork. This has a travel range of 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox Performance Float DPX2 rear shock model, which has a travel of 165mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the ONE-SIXTY 4000 bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The ONE-SIXTY 4000 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
ONE-SIXTY 4000 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the ONE-SIXTY 4000. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
