Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 180mm -
Travel Rear 171mm -
Fork Suntour DUROLUX
-
Groupset CUES -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-SIXTY FR LITE III, 171mm suspension travel mullet, material: aluminium, 29x2.5" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard
Suspension Fork
SR Suntour Durolux 38 RC, Air, 180mm suspension travel, Tapered, xxmm fork offset, 29x2.60" max. wheelsize
Rear Shock
DVO Jade X D3, coil, spring rate per size XSHORT and SHORT 300 lbs, MID: 350 lbs, LONG: 400 lbs, XLONG: 450 lbs
Drivetrain
Rear Derailleur
Shimano CUES U6000, GS
Shift Levers
Shimano SL-MT500-L / Shimano CUES U6000
Cassette
Shimano LG300, 11-48 teeth, 10 speed
Crank
MERIDA Expert TR, 32 teeth, 170 mm for all sizes
Bottom Bracket
BSA, 73mm, threaded
Chain
Shimano LG500
Chain Guide
MERIDA EXPERT TR ISCG05
Wheels
Front Hub
Shimano TC500-B / Shimano TC500-HM-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TC500-B / Shimano TC500-HM-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP TR II, 110x15mm width front hub, 148x12mm width rear hub, 28mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), front 29", rear 27.5"
Spokes
Double Butted Black stainless
Tires
Front: Continental Kryptotal-F, 29x2.4", fold, TR, Enduro casing, Soft Compund, Rear: Continental Kryptotal-F, 29x2.4", fold, TR, Enduro casing, Soft Compund
Brakes
Brakes
Tektro Gemini HD-M535, 4 piston
Cockpit
Stem
MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0° stem angle, 40 mm
Handlebar
MERIDA EXPERT TR II, material: aluminium, 780mm width, XS/S 18mm rise, M/L/XL 30mm rise
Headset
Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA EXPERT TR II, 34.9mm diameter, 0mm setback, XS/S: 150mm travel seatpost - M: 170mm travel seatpost - L/XL: 200mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XShort | Short | Mid | Long | XLong |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.516 mm | 1.419 mm | 1.336 mm | 1.278 mm | 1.239 mm |
| Front Center | 759 mm | 786 mm | 814 mm | 844 mm | 877 mm |
| Rake | 37 mm | 37 mm | 37 mm | 35 mm | 34 mm |
| Trail | 145 mm | 145 mm | 145 mm | 148 mm | 149 mm |
| Stack | 620 mm | 620 mm | 620 mm | 629 mm | 643 mm |
| Reach | 409 mm | 437 mm | 464 mm | 492 mm | 519 mm |
| Top Tube Length | 537 mm | 564 mm | 591 mm | 623 mm | 655 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 400 mm | 410 mm | 425 mm | 445 mm | 470 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 95 mm | 95 mm | 95 mm | 105 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 437 mm | 437 mm |
| Wheelbase | 1193 mm | 1220 mm | 1248 mm | 1281 mm | 1314 mm |
| Bottom Bracket Drop | 2 mm | 2 mm | 2 mm | 2 mm | 2 mm |
| Standover Height | 735 mm | 740 mm | 743 mm | 740 mm | 735 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
About this model
ONE-SIXTY FR 400 completes the Merida One Sixty model. Merida released 37 bikes variations of this model so far. You can easily view all of the Merida One Sixty bikes models from 2024, here.
Model range prices
Merida ONE-SIXTY FR 400 2024 is the most economical model, with a starting price of 3406$. Merida ONE-SIXTY FR 600 2024 on the other hand costs 4257$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro bikes average price
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2024 and its price was 3406$. If we compare this with the average Enduro bike cost we notice that the price is 5.67% smaller.
Overview of components
Fork
The Suntour DUROLUX is included from the factory. It has a travel distance of 180mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is DVO Jade X D3, with a travel distance of 171mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on ONE-SIXTY FR 400 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida ONE-SIXTY FR 400 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Dropper post
The Merida model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
