Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 180mm -
Travel Rear 171mm -
Fork DVO Onyx SC
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-SIXTY FR LITE III, 171mm suspension travel mullet, material: aluminium, 29x2.5" max. wheelsize, 148x12mm axle standard, BSA bottom bracket standard
Suspension Fork
DVO Onyx 38 D2, Air, 180mm suspension travel, tapered, 44mm Offset, 29"
Rear Shock
DVO Jade X D2, coil, spring rate per size XSHORT and SHORT 300 lbs, MID: 350 lbs, LONG: 400 lbs, XLONG: 450 lbs
Drivetrain
Rear Derailleur
Shimano Deore M6100, SGS
Shift Levers
Shimano SL-MT500-IL / Shimano Deore M6100
Cassette
Shimano Deore M6100, 10-51 teeth, 12 speed
Crank
Shimano Deore MT512, 32 teeth, 170 mm for all sizes
Bottom Bracket
Shimano BB-MT-501, 24mm
Chain
KMC X12
Chain Guide
MERIDA EXPERT TR ISCG05
Wheels
Front Hub
Shimano TC500-B / Shimano TC500-MS-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano TC500-B / Shimano TC500-MS-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA EXPERT TR II, 110x15mm width front hub, 148x12mm width rear hub, 28mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), front 29", rear 27.5"
Spokes
Double Butted Black stainless
Tires
Front: Continental Kryptotal-F, 29x2.4", fold, TR, Enduro casing, Soft Compund, Rear: Continental Kryptotal-F, 29x2.4", fold, TR, Enduro casing, Soft Compund
Brakes
Brakes
TRP Trail Evo HD-M843, 4 piston
Cockpit
Stem
MERIDA EXPERT eTRII, material: aluminium, 35mm diameter, 0° stem angle, 40 mm
Handlebar
MERIDA EXPERT TR II, material: aluminium, 780mm width, XS/S 18mm rise, M/L/XL 30mm rise
Headset
Acros ICR MERIDA EXTERNAL neck, Upper and lower IPS sealing
Seat
Saddle
MERIDA COMP SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA TEAM TR II, 34.9mm diameter, 0mm setback, all sizes 30-230mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XShort | Short | Mid | Long | XLong |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.516 mm | 1.419 mm | 1.336 mm | 1.278 mm | 1.239 mm |
| Front Center | 759 mm | 786 mm | 814 mm | 844 mm | 877 mm |
| Rake | 37 mm | 37 mm | 37 mm | 35 mm | 34 mm |
| Trail | 145 mm | 145 mm | 145 mm | 148 mm | 149 mm |
| Stack | 620 mm | 620 mm | 620 mm | 629 mm | 643 mm |
| Reach | 409 mm | 437 mm | 464 mm | 492 mm | 519 mm |
| Top Tube Length | 537 mm | 564 mm | 591 mm | 623 mm | 655 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 400 mm | 410 mm | 425 mm | 445 mm | 470 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 95 mm | 95 mm | 95 mm | 105 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 437 mm | 437 mm |
| Wheelbase | 1193 mm | 1220 mm | 1248 mm | 1281 mm | 1314 mm |
| Bottom Bracket Drop | 2 mm | 2 mm | 2 mm | 2 mm | 2 mm |
| Standover Height | 735 mm | 740 mm | 743 mm | 740 mm | 735 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
ONE-SIXTY FR 600 is a Merida One Sixty model. Merida launched 37 bikes of this model so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Merida ONE-SIXTY FR 400 2024 is the cheapest bike model and costs 3406$. Merida ONE-SIXTY FR 600 2024 is the most expensive one and costs 4257$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2024 for 4257$. Comparing the average cost of an Enduro bike to this one, you will see that ONE-SIXTY FR 600 price is 18.28% more expensive.
Overview of components
Fork
The fork installed on this bike is the DVO Onyx SC model. The travel on this model is 180mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Merida ONE-SIXTY FR 600 bike has the DVO Jade X D2 model installed, and has a travel of 171mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the ONE-SIXTY FR 600 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Dropper post
Merida ONE-SIXTY FR 600 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
