Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-TWENTY LITE, 120mm suspension travel, material: aluminium, 29 wheelsize, 148x12mm axle standard, BB92 bottom bracket standard, MUK 33 Hanger
Suspension Fork
SR Suntour XCR34 LOR, Air, 130mm suspension travel, Tapered, lockout, 51mm fork offset
Rear Shock
SR Suntour Unair TR LOR8, lockout
Drivetrain
Rear Derailleur
Shimano Deore M5100 Shadow+, SGS
Shift Levers
Shimano SL -MT500-L / Shimano Deore M5100
Cassette
Shimano Deore M5100, 11-51 teeth, 11 speed
Crank
Shimano Deore M5100, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
Shimano MT500-PA pressfit
Chain
KMC X11
Wheels
Front Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA COMP CC, 20mm inner width, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Rekon, 29x2.4", wire, Rear: Maxxis Rekon, 29x2.4", wire
Brakes
Brakes
Tektro M275, 2 piston
Cockpit
Stem
MERIDA COMP CC, material: aluminium, 31.8mm diameter, 7° stem angle, 60 mm
Handlebar
MERIDA EXPERT CC, material: aluminium, 740mm width, 10mm rise
Headset
FSA NO.47/50
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP TR, 30.9mm diameter, 0mm setback, S: 100mm travel seatpost - M: 125mm travel seatpost - L/XL: 150mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.395 mm | 1.354 mm | 1.318 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 709 mm | 729 mm | 753 mm | 776 mm |
| Rake | 51 mm | 51 mm | 52 mm | 50 mm |
| Trail | 101 mm | 101 mm | 100 mm | 102 mm |
| Stack | 607 mm | 607 mm | 616 mm | 626 mm |
| Reach | 415 mm | 435 mm | 455 mm | 475 mm |
| Top Tube Length | 572 mm | 592 mm | 614 mm | 637 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 67.3 ° | 67.3 ° | 67.3 ° | 67.3 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1141 mm | 1161 mm | 1185 mm | 1208 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 707 mm | 730 mm | 759 mm | 787 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
ONE-TWENTY 400 is part of the Merida One Twenty model. Merida launched 86 bikes of this model so far. Take a sneak peek at all Merida One Twenty bikes models from 2023, by clicking here.
Model range prices
Merida ONE-TWENTY RC 300 2023 is the cheapest bike model and costs 1528$. Merida ONE-TWENTY 600 2023 is the most expensive one and costs 2919$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 2311$. In conclusion, this bike price is 19.52% smaller than the price of the average Trail bike.
Overview of components
Fork
The ONE-TWENTY 400 comes factory-installed with the Suntour XCR Air fork. This has a travel range of 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Merida ONE-TWENTY 400 bike has the SR Suntour Unair TR LOR8 model installed, and has a travel of 120mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The ONE-TWENTY 400 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The ONE-TWENTY 400 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Merida ONE-TWENTY 400 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the ONE-TWENTY 400. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
