Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Select
-
Groupset SLX, XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ONE-TWENTY CF4, 120mm suspension travel, material: carbon, 29x2.35" max. wheelsize, 148x12mm axle standard, BB92 bottom bracket standard
Suspension Fork
Rock Shox Pike Select, Air, 130mm suspension travel, Tapered, 42mm fork offset, 29x2.6" max. wheelsize
Rear Shock
Rock Shox Deluxe Select+, lockout
Drivetrain
Rear Derailleur
Shimano SLX M7100 Shadow+, SGS
Shift Levers
Shimano SL -MT500-IL / Shimano XT, Multi Release
Cassette
Shimano Deore M6100, 10-51 teeth, 12 speed
Crank
Race Face Aeffect, 32 teeth, 170 mm-S, 175 mm-M up
Bottom Bracket
Race Face BB BB92– Ø24mm
Chain
KMC X12
Wheels
Front Hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub
Shimano SLX, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rims
MERIDA EXPERT TR, 29mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Dissector, 29x2.4", fold, TR EXO 3C MaxxTerra
Brakes
Brakes
Shimano SLX M7120, 4 piston
Cockpit
Handlebar
MERIDA EXPERT TR, material: aluminium, 780mm width, 20mm rise
Headset
FSA NO.47/50
Seat
Saddle
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA EXPERT TR, 30.9mm diameter, 0mm setback, S: 125mm travel seatpost - M 150mm travel seatpost - L/XL 170mm travel seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.395 mm | 1.354 mm | 1.318 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 709 mm | 729 mm | 753 mm | 776 mm |
| Rake | 51 mm | 51 mm | 52 mm | 50 mm |
| Trail | 101 mm | 101 mm | 100 mm | 102 mm |
| Stack | 607 mm | 607 mm | 616 mm | 626 mm |
| Reach | 415 mm | 435 mm | 455 mm | 475 mm |
| Top Tube Length | 572 mm | 592 mm | 614 mm | 637 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 67.3 ° | 67.3 ° | 67.3 ° | 67.3 ° |
| Head Tube Length | 95 mm | 95 mm | 105 mm | 115 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1141 mm | 1160 mm | 1185 mm | 1208 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 703 mm | 718 mm | 745 mm | 770 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
ONE-TWENTY 6000 belongs to the Merida One Twenty model. 86 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Merida ONE-TWENTY RC 300 2023 is the most affordable bike of this model and has a price of 1528$. On the other hand, Merida ONE-TWENTY 600 2023, is the most expensive and costs 2919$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork
Merida ONE-TWENTY 6000 2023 bike is equipped with the RockShox Pike Select fork, and has 130mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The ONE-TWENTY 6000 has a rear shock with a travel of 120mm. The model Rock Shox Deluxe Select+ is the one installed in this bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When it comes to wheels, the ONE-TWENTY 6000 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The ONE-TWENTY 6000 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
ONE-TWENTY 6000 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Merida model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
