Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA Disc LITE, material: aluminium, 700x28C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86 bottom bracket standard, MUK 36 Hanger
Suspension Fork
SCULTURA CF2 Disc, 700x28C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Sora, GS
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora
Cassette
Microshift CS-9S, 11-28 teeth, 9 speed
Crank
FSA Omega, 50-34 teeth, 165 mm-XXS, 170 mm-XS/S, 172.5 mm-SM/ML, 175 mm-L/XL
Bottom Bracket
FSA BB-AL86/Ø19
Chain
KMC M99
Wheels
Front Hub
Joytech D981-12 / Joytech D982TSE-R, 100x12mm width front hub, 28 spoke holes, 6 bolt, 142x12mm width rear hub, 28 spoke holes, 6 bolt
Rear Hub
Joytech D981-12 / Joytech D982TSE-R, 100x12mm width front hub, 28 spoke holes, 6 bolt, 142x12mm width rear hub, 28 spoke holes, 6 bolt
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Black stainless
Tires
Maxxis Pursuer, 700x25C, fold
Brakes
Brakes
Promax DSK-330R, Mechanical Disc
Brake Levers
Shimano Sora
Disk Rotors
Promax 160G, 160mm
Cockpit
Stem
MERIDA COMP CC, 31.8mm diameter, material: aluminium, -6° stem angle, 80 mm-XXS/XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL
Handlebar
MERIDA EXPERT SL, material: aluminium, 380mm(XXS), 400mm (XS-S), 420mm (M), 440mm (L-XL)
Headset
MERIDA M2339
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 27.2mm diameter, 5mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXXS | XXS | XS | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.39 mm | 1.43 mm | 1.45 mm | 1.45 mm | 1.48 mm | 1.51 mm | 1.55 mm |
| Bottom Bracket Height | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 580 mm | 583 mm | 584 mm | 580 mm | 586 mm | 596 mm | 606 mm | 615 mm |
| Rake | 55 mm | 45 mm | 45 mm | 44 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 61 mm | 68 mm | 68 mm | 63 mm | 56 mm | 56 mm | 56 mm | 53 mm |
| Stack | 491 mm | 512 mm | 522 mm | 535 mm | 548 mm | 567 mm | 586 mm | 612 mm |
| Reach | 359 mm | 369 mm | 366 mm | 368 mm | 379 mm | 383 mm | 387 mm | 394 mm |
| Top Tube Length | 493 mm | 508 mm | 513 mm | 523 mm | 538 mm | 553 mm | 568 mm | 583 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm | 150 mm | 170 mm | 190 mm | 215 mm |
| Chainstay Length | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm | 401 mm |
| Wheelbase | 971 mm | 975 mm | 976 mm | 972 mm | 978 mm | 988 mm | 998 mm | 1007 mm |
| Bottom Bracket Drop | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 661 mm | 690 mm | 713 mm | 737 mm | 755 mm | 772 mm | 791 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
SCULTURA 200 is part of the Merida Scultura model. There are 214 bikes that carry this model name. You can easily view all of the Merida Scultura bikes models from 2022, here.
Model range prices
Merida SCULTURA RIM 100 2022 is the most affordable bike of this model and has a price of 1077$. On the other hand, Merida SCULTURA 10K 2022, is the most expensive and costs 12164$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Merida SCULTURA 200 price was 1368$. Doing a quick comparison, we notice that SCULTURA 200 price is 144.88% smaller than the average cost of a Race bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the SCULTURA 200 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SCULTURA 200 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
