Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA Disc LITE, material: aluminium, 700x28C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86 bottom bracket standard, MUK 36 Hanger
Suspension Fork
SCULTURA CF2 Disc, 700x28C max. wheelsize
Drivetrain
Rear Derailleur
Shimano 105, GS
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 Disc
Cassette
Shimano CS-R7000, 11-30 teeth, 11 speed
Crank
Shimano 105, 50-34 teeth, 165 mm-XXS, 170 mm-XS/S, 172.5 mm-SM/ML, 175 mm-L/XL
Bottom Bracket
SM-BB71-41B, Pressfit 86.5
Chain
KMC X11
Wheels
Front Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 28 spoke holes, Centerlock, 142x12mm width rear hub, 28 spoke holes, Centerlock
Rear Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 28 spoke holes, Centerlock, 142x12mm width rear hub, 28 spoke holes, Centerlock
Rims
MERIDA EXPERT SL, 17mm inner width, 22mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Maxxis Pursuer, 700x25C, fold
Brakes
Brakes
Shimano 105, Hydraulic Disc
Brake Levers
Shimano 105
Disk Rotors
Shimano RT10, 160mm
Cockpit
Stem
MERIDA EXPERT CC, 31.8mm diameter, material: aluminium, -5° stem angle, 80 mm-XXS/XS, 90 mm-S, 100 mm-SM/ML, 110 mm-L/XL
Handlebar
MERIDA EXPERT SL, material: aluminium, 380mm(XXS), 400mm (XS-S), 420mm (M), 440mm (L-XL)
Headset
MERIDA M2331
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA EXPERT CC, 27.2mm diameter, 15mm setback, Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.44 mm | 1.47 mm | 1.51 mm | 1.55 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 580 mm | 586 mm | 596 mm | 606 mm | 615 mm |
| Rake | 44 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 63 mm | 56 mm | 56 mm | 56 mm | 53 mm |
| Stack | 540 mm | 553 mm | 572 mm | 591 mm | 617 mm |
| Reach | 373 mm | 384 mm | 388 mm | 392 mm | 399 mm |
| Top Tube Length | 528 mm | 543 mm | 558 mm | 573 mm | 588 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 500 mm | 520 mm | 540 mm | 560 mm | 590 mm |
| Head Tube Angle | 72 ° | 73 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 140 mm | 150 mm | 170 mm | 190 mm | 215 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 977 mm | 983 mm | 993 mm | 1003 mm | 1012 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 742 mm | 760 mm | 777 mm | 796 mm | 824 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
SCULTURA 400 is a Merida Scultura model. There are 214 bikes that carry this model name. You can easily view all of the Merida Scultura bikes models from 2022, here.
Model range prices
The most economical model, the Merida SCULTURA RIM 100 2022 has a starting price of 1077$. Merida SCULTURA 10K 2022 on the other hand is the most expensive at 12164$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2022 and its price was 2159$. In conclusion, this bike price is 55.16% smaller than the price of the average Race bike.
Overview of components
Fork material
SCULTURA 400 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the SCULTURA 400 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The SCULTURA 400 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
