Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA CF3 V, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12 mm axle standard, Pressfit 86,5
Suspension Fork
SCULTURA CF3 disc, material: carbon, 700x30C max. wheelsize, MERIDA EXPERT CC
Drivetrain
Rear Derailleur
Shimano 105, GS
Front Derailleur
Shimano 105
Shift Levers
Shimano 105 disc
Cassette
Shimano CS-R7100, 11-34 teeth, 12 speed
Crank
Shimano 105, 50-34 teeth, 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M, 175 mm-L/XL
Bottom Bracket
Shimano SM-BB71-41B, Pressfit 86.5 mm
Chain
Shimano CN-M6100-12
Wheels
Front Hub
VP CLK170F / VP CLK270R, 100x12 mm width front hub, 28 spoke holes, Centerlock, 142x12 mm width rear hub, 28 spoke holes, Centerlock
Rear Hub
VP CLK170F / VP CLK270R, 100x12 mm width front hub, 28 spoke holes, Centerlock, 142x12 mm width rear hub, 28 spoke holes, Centerlock
Rims
MERIDA EXPERT SL, 17 mm inner width, 22 mm height, material: aluminium, Tubeless ready (tubeless tape and valves not included)
Spokes
Double Butted Black stainless
Tires
Front: Maxxis Highroad, 700x28C, fold *tubeless ready, Rear: Maxxis Highroad, 700x28C, fold *tubeless ready
Brakes
Brakes
Shimano 105, Hydraulic disc
Brake Levers
Shimano 105
Cockpit
Stem
FSA SMR ACR, material: aluminium, -6° stem angle, 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
Handlebar
MERIDA EXPERT SLII, material: aluminium, 380 mm(XXS), 400 mm (XS), 420 mm (S-M-L), 440 mm (XL)
Headset
FSA ACR
Seat
Saddle
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA EXPERT CC, 27.2 mm diameter, 15 mm setback, material: Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.381 mm | 1.39 mm | 1.41 mm | 1.428 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 584 mm | 590 mm | 591 mm | 601 mm | 611 mm |
| Rake | 46 mm | 44 mm | 45 mm | 46 mm | 45 mm |
| Trail | 61 mm | 60 mm | 53 mm | 52 mm | 50 mm |
| Stack | 529 mm | 542 mm | 557 mm | 571 mm | 593 mm |
| Reach | 383 mm | 390 mm | 395 mm | 400 mm | 409 mm |
| Top Tube Length | 535 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 458 mm | 481 mm | 501 mm | 521 mm | 550 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 112 mm | 128 mm | 140 mm | 155 mm | 176 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 982 mm | 989 mm | 990 mm | 1000 mm | 1010 mm |
| Bottom Bracket Drop | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 745 mm | 765 mm | 782 mm | 800 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
SCULTURA 4000 belongs to the Merida Scultura model. 232 bikes variations carry this model name so far. You can easily view all of the Merida Scultura bikes models from 2024, here.
Model range prices
Merida SCULTURA 200 2024 is the most economical model, with a starting price of 1027$. Merida SCULTURA 10K 2024 on the other hand costs 8988$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
If you want an acceptable Race bike you should know that the average price is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2054$. If we compare this with the average Race bike cost we notice that the price is 63.1% smaller.
SCULTURA 4000 components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the SCULTURA 4000 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SCULTURA 4000 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
