Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Rival AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA CF3 V, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12 mm axle standard, Pressfit 86,5
Suspension Fork
SCULTURA CF3 disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
SRAM Rival eTap AXS, SS
Front Derailleur
SRAM Rival eTap AXS
Shift Levers
SRAM Rival eTAP AXS HRD
Cassette
SRAM XG-1250, 10-36 teeth, 12 speed
Crank
SRAM Rival eTap AXS, 48-35 teeth, Power Meter, 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M, 175 mm-L/XL
Bottom Bracket
SRAM Pressfit DUB, Presfit 86.5 mm
Chain
SRAM Rival
Wheels
Front Hub
MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Rear Hub
MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Rims
Vision SC30 DB, 100x12 mm width front hub, 142x12 mm width rear hub, 19 mm inner width, 33 mm height, Centerlock, material: carbon
Tires
Front: Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready, Rear: Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Brakes
Brakes
SRAM Rival eTap AXS, Hydraulic disc
Brake Levers
SRAM ED Rival eTap AXS
Cockpit
Stem
FSA SMR ACR, material: aluminium, -6° stem angle, 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
Handlebar
MERIDA EXPERT SLII, material: aluminium, 380 mm(XXS), 400 mm (XS), 420 mm (S-M-L), 440 mm (XL)
Headset
FSA ACR
Seat
Saddle
MERIDA EXPERT SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA TEAM SL, 27.2 mm diameter, 15 mm setback, Carbon, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.381 mm | 1.39 mm | 1.41 mm | 1.428 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 584 mm | 590 mm | 591 mm | 601 mm | 611 mm |
| Rake | 46 mm | 44 mm | 45 mm | 46 mm | 45 mm |
| Trail | 61 mm | 60 mm | 53 mm | 52 mm | 50 mm |
| Stack | 529 mm | 542 mm | 557 mm | 571 mm | 593 mm |
| Reach | 383 mm | 390 mm | 395 mm | 400 mm | 409 mm |
| Top Tube Length | 535 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 458 mm | 481 mm | 501 mm | 521 mm | 550 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 112 mm | 128 mm | 140 mm | 155 mm | 176 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 982 mm | 989 mm | 990 mm | 1000 mm | 1010 mm |
| Bottom Bracket Drop | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 745 mm | 765 mm | 782 mm | 800 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
SCULTURA 7000 belongs to the Merida Scultura model. Merida released 232 bikes variations of this model so far. You can easily view all of the Merida Scultura bikes models from 2024, here.
Model range prices
Merida SCULTURA 200 2024 is the most economical model, with a starting price of 1027$. Merida SCULTURA 10K 2024 on the other hand costs 8988$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2024 for 4109$. Comparing this to the average Race bike price, we see that the price is 22.66% more expensive.
SCULTURA 7000 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the SCULTURA 7000 model has 700c carbon wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SCULTURA 7000 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Merida SCULTURA 7000 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
