Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA CF5 V, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12 mm axle standard, Pressfit 86,5
Suspension Fork
SCULTURA CF5 disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
SRAM Force AXS
Front Derailleur
SRAM Force AXS
Shift Levers
SRAM FORCE AXS
Cassette
SRAM CS XG 1270 D1, 10-36 teeth, 12 speed
Crank
SRAM Force AXS, 50-37 teeth, Power Meter, 165 mm-XXS, 170 mm-XS, 172.5 mm-S/M, 175 mm-L/XL
Bottom Bracket
BB DUB PF ROAD, Pressfit 86.5 mm
Chain
SRAM Force
Wheels
Front Hub
MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Rear Hub
MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Rims
Reynolds BL 46 PRO DB, 100x12 mm width front hub, 142x12 mm width rear hub, 21 mm inner width, 46 mm height, Centerlock, material: carbon, Tubeless ready (tubeless tape and valves included)
Tires
Front: Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready, Rear: Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Brakes
Brakes
SRAM Force AXS, Hydraulic disc
Brake Levers
SRAM Force AXS
Cockpit
Stem
TEAM ONE-PIECE INTEGRATED, material: carbon, 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
Handlebar
TEAM SL 1P INTEGRATED, material: carbon, 400 mm (XXS-XS), 420 mm (S-M-L), 440 (XL)
Headset
MERIDA TEAM SL, VP-MRBHB (OP-203 neck)
Seat
Saddle
SCRATCH M5, V-mount adapter, incl. MERIDA minitool
Seatpost
MERIDA Team SL, 27.2 mm diameter, 15 mm setback, Carbon, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.381 mm | 1.39 mm | 1.41 mm | 1.428 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 584 mm | 590 mm | 591 mm | 601 mm | 611 mm |
| Rake | 46 mm | 44 mm | 45 mm | 46 mm | 45 mm |
| Trail | 61 mm | 60 mm | 53 mm | 52 mm | 50 mm |
| Stack | 529 mm | 542 mm | 557 mm | 571 mm | 593 mm |
| Reach | 383 mm | 390 mm | 395 mm | 400 mm | 409 mm |
| Top Tube Length | 535 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 458 mm | 481 mm | 501 mm | 521 mm | 550 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 112 mm | 128 mm | 140 mm | 155 mm | 176 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheelbase | 982 mm | 989 mm | 990 mm | 1000 mm | 1010 mm |
| Bottom Bracket Drop | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 745 mm | 765 mm | 782 mm | 800 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
SCULTURA 9000 completes the Merida Scultura model. There are 232 bikes that carry this model name. Take a sneak peek at all Merida Scultura bikes models from 2024, by clicking here.
Model range prices
The most economical model, the Merida SCULTURA 200 2024 has a starting price of 1027$. Merida SCULTURA 10K 2024 on the other hand is the most expensive at 8988$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5971$. If we compare this with the average Race bike cost we notice that the price is 78.24% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Merida SCULTURA 9000 2024, has a 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SCULTURA 9000 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Merida SCULTURA 9000 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
