Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA ENDURANCE CF3 II, material: carbon, 700x35C max./ 700x32C (with fender) max. wheelsize, 100x12/ 142x12 mm axle standard, BB86 bottom bracket standard
Drivetrain
Rear Derailleur
SRAM Force AXS
Front Derailleur
SRAM Force AXS
Shift Levers
SRAM FORCE AXS
Cassette
SRAM CS XG 1270 D1, 10-36 teeth, 12 speed
Crank
SRAM Force AXS, 48-35 teeth, Power Meter, 170 mm-XXS/XS/S, 172.5 mm-M/L, 175 mm-XL
Bottom Bracket
SRAM DUB PF ROAD, Pressfit 86.5 mm
Chain
SRAM Force
Wheels
Front Hub
MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Rear Hub
MERIDA EXPERT SL, including removable lever, 6/4 mm allen key
Rims
Reynolds ATR DB, 100x12 mm width front hub, 142x12 mm width rear hub, 23 mm inner width, 40 mm height, Centerlock, material: carbon, Tubeless ready (tubeless tape and valves included)
Tires
Front: Continental GP5000 S, 700x32C, fold, Rear: Continental GP5000 S, 700x32C, fold
Brakes
Brakes
SRAM Force AXS, Hydraulic disc
Brake Levers
SRAM Force AXS
Cockpit
Stem
TEAM ONE-PIECE INTEGRATED, material: carbon, 90 mm-XXS/XS, 100 mm-S/M, 110 mm-L, 120 mm-XL
Handlebar
TEAM SL 1P INTEGRATED, material: carbon, 400 mm (XXS-XS-S), 420 mm (M-L), 440 (XL)
Headset
MERIDA TEAM SL, VP-MRBHB (SE-301 neck)
Seat
Saddle
Prologo Scratch M5, V-mount adapter, incl. MERIDA minitool
Seatpost
MERIDA TEAM SL, 27.2 mm diameter, 15 mm setback, Carbon, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.508 mm | 1.503 mm | 1.537 mm | 1.55 mm | 1.584 mm |
| Bottom Bracket Height | 270 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 588 mm | 592 mm | 592 mm | 608 mm | 617 mm |
| Rake | 48 mm | 48 mm | 48 mm | 49 mm | 47 mm |
| Trail | 66 mm | 60 mm | 53 mm | 52 mm | 51 mm |
| Stack | 552 mm | 565 mm | 584 mm | 603 mm | 629 mm |
| Reach | 366 mm | 376 mm | 380 mm | 389 mm | 397 mm |
| Top Tube Length | 524 mm | 538 mm | 553 mm | 568 mm | 583 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 152 mm | 161 mm | 177 mm | 197 mm | 222 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 997 mm | 1001 mm | 1001 mm | 1017 mm | 1026 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 767 mm | 785 mm | 803 mm | 823 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
SCULTURA ENDURANCE 9000 belongs to the Merida Scultura model. 232 bikes variations carry this model name so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Merida SCULTURA 200 2024 is the most affordable bike of this model and has a price of 1027$. On the other hand, Merida SCULTURA 10K 2024, is the most expensive and costs 8988$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even if your budget is less than the average, you might still be able to get a top-quality Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
SCULTURA ENDURANCE 9000 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the SCULTURA ENDURANCE 9000 model has 700c carbon wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SCULTURA ENDURANCE 9000 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
