Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SCULTURA CF5 V, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86,5
Suspension Fork
SCULTURA CF5 disc, material: carbon, 700x30C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Dura Ace Di2
Front Derailleur
Shimano Dura Ace Di2
Shift Levers
Shimano Dura Ace disc Di2
Cassette
Shimano CS-R9200, 11-30 teeth, 12 speed
Crank
Shimano Dura Ace, 52-36 teeth, Power Meter, 165 mm-XXS/XS, 170 mm-S, 172.5 mm-M, 175 mm-L/XL
Bottom Bracket
SM-BB92-41B, Pressfit 86.5
Chain
Shimano CN-M9100-12
Wheels
Front Hub
MERIDA EXPERT SL, including removable lever, 6/4mm allen key
Rear Hub
MERIDA EXPERT SL, including removable lever, 6/4mm allen key
Rims
METRON 45 SL Clincher TL Disc, 100x12mm width front hub, 142x12mm width rear hub, 18mm inner width, 45mm height, Centerlock, material: carbon, Tubeless ready (tubeless tape and valves included)
Tires
Continental Grand Prix 5000, 700x28C, fold
Brakes
Brakes
Shimano Dura Ace, Hydraulic disc
Brake Levers
Shimano Dura Ace disc
Disk Rotors
Shimano RT900, 160mm
Cockpit
Stem
TEAM ONE-PIECE INTEGRATED, material: carbon, 90 mm-XXS/XS, 100 mm-S, 110 mm-M, 120 mm-L/XL
Handlebar
TEAM SL 1P INTEGRATED, material: carbon, 400mm (XXS-XS-S), 420mm (M), 440 (L-XL)
Headset
MERIDA custom
Seat
Saddle
SCRATCH M5
Seatpost
MERIDA Team SL, 27.2mm diameter, 15mm setback, Carbon, S-Flex
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.38 mm | 1.39 mm | 1.41 mm | 1.43 mm | 1.45 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 270 mm | 270 mm | 270 mm | 270 mm |
| Front Center | 587 mm | 584 mm | 590 mm | 591 mm | 601 mm | 611 mm |
| Rake | 45 mm | 46 mm | 44 mm | 45 mm | 46 mm | 45 mm |
| Trail | 71 mm | 61 mm | 60 mm | 53 mm | 52 mm | 50 mm |
| Stack | 518 mm | 530 mm | 543 mm | 558 mm | 572 mm | 594 mm |
| Reach | 378 mm | 384 mm | 391 mm | 396 mm | 401 mm | 410 mm |
| Top Tube Length | 521 mm | 536 mm | 546 mm | 561 mm | 576 mm | 591 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 435 mm | 458 mm | 481 mm | 501 mm | 521 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72.5 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 105 mm | 112 mm | 128 mm | 140 mm | 155 mm | 176 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 986 mm | 983 mm | 990 mm | 991 mm | 1001 mm | 1011 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 722 mm | 746 mm | 766 mm | 783 mm | 801 mm | 824 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
SCULTURA TEAM completes the Merida Scultura model. Merida released 214 bikes variations of this model so far. You can easily view all of the Merida Scultura bikes models from 2022, here.
Model range prices
The most economical model, the Merida SCULTURA RIM 100 2022 has a starting price of 1077$. Merida SCULTURA 10K 2022 on the other hand is the most expensive at 12164$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The SCULTURA TEAM 2022 bike is equipped with 700c carbon wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The SCULTURA TEAM comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
