Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SILEX LITE, material: aluminium, 700x38C / 650Bx45C max.WHS, 100x12/142x12mm axle standard, BB86 bottom bracket standard
Suspension Fork
MERIDA SILEX CF2, Tapered, material: carbon, 700x38C / 650Bx45C max. wheelsize
Drivetrain
Rear Derailleur
Shimano Sora, GS
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora
Cassette
Shimano CS-HG200, 11-32 teeth, 9 speed
Crank
FSA Omega, 48-32 teeth, 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL
Bottom Bracket
FSA PF86 MegaExo
Chain
KMC M99
Wheels
Front Hub
VP 173SB / VP 273SB, 100x12mm width front hub, 32 spoke holes, 6 bolt, 142x12mm width rear hub, 32 spoke holes, 6 bolt
Rear Hub
VP 173SB / VP 273SB, 100x12mm width front hub, 32 spoke holes, 6 bolt, 142x12mm width rear hub, 32 spoke holes, 6 bolt
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Front: Maxxis Rambler, 700x38C, fold, TR, EXO, Rear: Maxxis Rambler, 700x38C, fold, TR, EXO
Brakes
Brakes
Promax DSK-330R, Mechanical disc
Brake Levers
Shimano Sora
Cockpit
Stem
MERIDA COMP CC, material: aluminium, 31.8mm diameter, -6° stem angle, 80 mm all sizes
Handlebar
MERIDA EXPERT GR, material: aluminium, 400mm (XS-S), 420mm (M), 440mm (L/XL)
Headset
MERIDA M2331
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 0mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.56 mm | 1.55 mm | 1.54 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 615 mm | 641 mm | 663 mm | 684 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm |
| Stack | 608 mm | 627 mm | 646 mm | 665 mm |
| Reach | 382 mm | 402 mm | 417 mm | 432 mm |
| Top Tube Length | 556 mm | 581 mm | 602 mm | 622 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1036 mm | 1062 mm | 1084 mm | 1105 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 746 mm | 774 mm | 801 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
SILEX 200 completes the Merida Silex model. Merida launched 43 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Merida SILEX 300 2023 is the cheapest bike model and costs 1273$. Merida SILEX 4000 2023 is the most expensive one and costs 2615$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Merida released this model in 2023, its price was 1490$. In conclusion, this bike price is 65.23% smaller than the price of the average Gravel bike.
SILEX 200 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the SILEX 200 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Merida SILEX 200 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
